LED Driver IC

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Features:

Switch mode controller for single switch LED drivers
Enhanced drop-in replacement to the HV9910
Open loop peak current controller
Internal 8.0V to 450V linear regulator
Constant frequency or constant off-time operation
Linear and PWM dimming capability
Requires few external components for operation

Description:

The HV9910B is an open loop current mode control LED driver IC.The HV9910B can be programmed to operate in either a constantfrequency or constant off-time mode. It includes an 8450V linearregulator which allows it to work from a wide range of inputvoltages without the need for an external low voltage supply
The HV9910B includes a PWM dimming input that can accept anexternal control signal with a duty ratio of 0100% and a frequencyof up to a few kilohertz. It also includes a 0250mV linear dimminginput which can be used for linear dimming of the LED current. TheHV9910B is ideally suited for buck LED drivers
Since the HV9910B operates in open loop current mode control,the controller achieves good output current regulation without theneed for any loop compensation. PWM dimming response is limitedonly by the rate of rise and fall of the inductor current, enablingvery fast rise and fall times
The HV9910B requires only three external components (apart fromthe power stage) to produce a controlled LED current making it anideal solution for low cost LED drivers

Switch mode controller for single switch LED drivers

Enhanced drop-in replacement to the HV9910

Open loop peak current controller

Internal 8.0V to 450V linear regulator

Constant frequency or constant off-time operation

Linear and PWM dimming capability

Requires few external components for operation

The HV9910B is an open loop current mode control LED driver IC.The HV9910B can be programmed to operate in either a constantfrequency or constant off-time mode. It includes an 8450V linearregulator which allows it to work from a wide range of inputvoltages without the need for an external low voltage supply

The HV9910B includes a PWM dimming input that can accept anexternal control signal with a duty ratio of 0100% and a frequencyof up to a few kilohertz. It also includes a 0250mV linear dimminginput which can be used for linear dimming of the LED current. TheHV9910B is ideally suited for buck LED drivers

Since the HV9910B operates in open loop current mode control,the controller achieves good output current regulation without theneed for any loop compensation. PWM dimming response is limitedonly by the rate of rise and fall of the inductor current, enablingvery fast rise and fall times

The HV9910B requires only three external components (apart fromthe power stage) to produce a controlled LED current making it anideal solution for low cost LED drivers
