Single-mode/Multimode LC Fiber Optic Patch Cords
  • Single-mode/Multimode LC Fiber Optic Patch Cords
Single-mode/Multimode LC Fiber Optic Patch Cords

Single-mode/Multimode LC Fiber Optic Patch Cords

Get Latest Price
Payment Type:
Telegraphic Transfer (TT, T/T)
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: Telegraphic Transfer (TT,T/T)
Product Description
Product Description
  • Applications:
    • Active device termination
    • FTTX applications
    • Telecommunication networks
    • Multimedia
  • Characteristics:
    • High return loss
    • Low insertion loss
    • Good interchangeability and duplication
    • Made of high quality ceramic sleeve
  • LC fiber-optic patch cable cord descriptions:
    • LC fiber patch cables uses a 1.25mm ferrule, half the size of the ST patch cable
    • LC fiber patch cable has good performance and is highly favored for single mode patch cord
    • LC cable comply with IEC, Telcordia, ANSI/EIA/TIA
    • The connector of LC patch cable is used on 1.6mm/2.0mm as well as 3.0mm cable
    • It is small form factor connector suit for dense installations
    • LC has single mode and multimode versions, simplex or duplex, PC, UPC or APC
    • LC features compact, pull-proof design and RJ-45 style interface
    • Our LC fiber-optic patch cables are compliant to IEC and EIA/TIA standards, they are compatible to use with equipment from other companies
    • We supply the LC fiber-optic connectors, jumper cables, adapters, LC attenuators and related LC fiber optic components
  • Specifications for LC patch cable:
    • Insert loss:
      • Single mode patch cable: ≤0.3dB
      • Multimode patch cable: ≤0.3dB
    • Return loss:
      • Single mode patch cord:
        • PC: ≤-50dB
        • UPC: ≤-55dB
        • APC: ≤-60dB
    • Multimode patch cord: ≥20dB
    • Duplicated: ≤0.1dB
    • Interchangeable: ≤0.2dB
    • Inserts pulls out the number of time: ≥1,000 times
    • Working temperature: -40-80°C
    • Colors:
      • Single mode: yellow
      • Multimode: orange
  • Active device termination
  • FTTX applications
  • Telecommunication networks
  • Multimedia
  • High return loss
  • Low insertion loss
  • Good interchangeability and duplication
  • Made of high quality ceramic sleeve
  • LC fiber patch cables uses a 1.25mm ferrule, half the size of the ST patch cable
  • LC fiber patch cable has good performance and is highly favored for single mode patch cord
  • LC cable comply with IEC, Telcordia, ANSI/EIA/TIA
  • The connector of LC patch cable is used on 1.6mm/2.0mm as well as 3.0mm cable
  • It is small form factor connector suit for dense installations
  • LC has single mode and multimode versions, simplex or duplex, PC, UPC or APC
  • LC features compact, pull-proof design and RJ-45 style interface
  • Our LC fiber-optic patch cables are compliant to IEC and EIA/TIA standards, they are compatible to use with equipment from other companies
  • We supply the LC fiber-optic connectors, jumper cables, adapters, LC attenuators and related LC fiber optic components
  • Insert loss:
    • Single mode patch cable: ≤0.3dB
    • Multimode patch cable: ≤0.3dB
  • Return loss:
    • Single mode patch cord:
      • PC: ≤-50dB
      • UPC: ≤-55dB
      • APC: ≤-60dB
  • Multimode patch cord: ≥20dB
  • Duplicated: ≤0.1dB
  • Interchangeable: ≤0.2dB
  • Inserts pulls out the number of time: ≥1,000 times
  • Working temperature: -40-80°C
  • Colors:
    • Single mode: yellow
    • Multimode: orange
  • Single mode patch cable: ≤0.3dB
  • Multimode patch cable: ≤0.3dB
  • Single mode patch cord:
    • PC: ≤-50dB
    • UPC: ≤-55dB
    • APC: ≤-60dB
  • PC: ≤-50dB
  • UPC: ≤-55dB
  • APC: ≤-60dB
  • Single mode: yellow
  • Multimode: orange
