ST MM DX Fiber-optic Patch Cord Assembly

ST MM DX Fiber-optic Patch Cord Assembly

Get Latest Price

Payment Type:: T/T, L/C, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C, Western Union

Product Description

Applications:

CATV, metro
Active device termination, test equipment
Telecommunication networks, Local Area Networks (LANs), data processing networks
Premise installations, Wide Area Networks (WANs)
Industrial, medical and military

Characteristics:

High return loss
Low insertion loss
Good interchangeability and duplication
Made by high-quality ceramic sleeve

ST fiber-optic patch cable cord description:

ST patch cable is easy to insert and remove
If you experience high light loss, try to reconnect it
The ST patch cord is old generation of connectors, but is still commonly used for multi-mode networks
ST patch cable are rated for 500 mating cycles
ST fiber cable connector has bayonet-style housing and a long spring-loaded ferrule hold the fiber
They are available in both multi-mode and single mode versions
Horizontally mounted simplex and duplex adapters are available with metal or plastic housing, with a choice of phosphor bronze or zirconia split sleeve
The ST Fiber-optic Patch Cable is one of the older generations of connector, but is still widely used for multimode networks, including LANs for buildings and campuses

ST fiber patch cable specifications:

Insert loss:
- Single mode patch cable: ≤0.3dB
- Multi-mode patch cable: ≤0.3dB
Return Loss:
- Single mode patch cord: PC ≤-50dB, UPC≤-55dB, APC≤-60dB
- Multi-mode patch cord: ≥20dB
Duplicated: ≤0.1dB
Interchangeable: ≤0.2dB
Inserts pulls out the number of times (time): ≥1000
Working temperature: -40 - +80°C
Color:
- Single mode: yellow
- Multi-mode: orange
