Wall Mount 12V 1A AC/DC Adapter, 12W

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Output power: 22V DC maximum

Protections: short-circuit/overload/over-voltage

100% full loading burn-in test

3 years warranty

Output power range: 12V 1A

Adapter weight: 0.074g/pc

Input rated voltage: 86 to 264V AC

Input frequency range: 47 to 63Hz

Input current: less than 0.5A

Input inrush current: less than 50A

Efficiency: 80% (minimum) at rated voltage

DC output voltage: 9V ±5%

DC output current: 1A

DC output power: 12W

Leakage current: less than 1mA

Standby power: less than 0.5W

DC connector: 5.5 x 2.1 x 11mm (optional)

DC cable: 1.5m cable (optional)

Ripple and noise: less than 120mV at full road with 20MHzbandwidth

Turn on delay time: less than 3s (AC 110V, full load)

Dielectric voltage A IEC320 three-pin input, output: (FG) 3000VAC/minute

Safety protections:

Operating temperature: 0 to 55°C

Storage temperature: -20 to 85°C

Output voltage protection (150 to 180% rated outputcurrent)

Output current protection (150 to 180% rated outputcurrent)

Short current protection
