USB Serial Adapter with 5V, 1.5A US Plug

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Specifications:

AC input:

DC output:

Environment requirement:

Safety requirements:

Input: 90 to 264V

Output: 5V/1.5A

LED power indicator

Over-heat and short-circuit protections

Meet all related safety standard

Suitable for mobile phones, MP3, MP4 players, iPhone and more

With CE mark

AC input voltage: 90 to 264V AC 50 to 60Hz

Inrush current: 30A (240V AC at 25°C)

Input current limiting: 2.5A (under minimum AC input and full load)

Efficiency: 72%

DC voltage regulation

Parameter V1: 5V

Line regulation: ±5.0%

Load regulation: ±5.0%

Cross regulation: N/A

Working temperature: 0 to 40°C

Storage temperature range: -10 to +85°C

Working humidity: 25 to 90% RH relative humidity (non-condensing)

Storage humidity range: 10 to 90% RH relative humidity (non-condensing)

MTBF: 50K hours (25°C, full load and rated voltage input)

Standards: meet IEC60950 to 1 standard requirement

Leakage current: not exceed 0.25mA at 220V AC/50Hz

Insulation resistance: ≥50MΩ, 500V DC
