Rear-view System, 7-inch Digital TFT Panel, Built-in GPS Navigation, Wireless Support for Option

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T or L/C

Product Description

Monitor specifications:

Screen size: 7-inch digital TFT panel

Rear view monitor: supports 4 camera inputs

Single view/split view/quad view selectable

Digital high backlight LCD monitor

With built-in GPS navigation, supports wireless

Brightness: 450cdm

Touchscreen button

9 languages OSD display

PAL/NTSC optional, mirror/normal image optional

Automatically turn on when the reversing gear is engaged

Trigger priority: CAM 1>CAM 2>CAM 3>CAM 4

Built-in speaker (optional)

Heavy duty reversing

OSD menu

Contrast, color and brightness adjustable

View angle range: (left/right) 65°, (top) 40°, (down) 15°

Camera specifications:

Type: high resolution backup camera

Image sensor: 1/3" CCD

TV system: NTSC/PAL optional

Effective pixels:

Horizontal resolution: 420TV lines

Lens angle: 120°

Minimum illumination: 0 lux (LED on)

IR LED: 16pcs for night vision distance 45ft

Audio function

Operating temperature: -20~+70°C RH 95% maximum

Lens: f=2.8mm

Power supply: DC 12V

NW: 350g

Waterproof rate: IP68

Shell material: aluminum alloy

N: 510x492 pixels

P: 500x582 pixels
