32CH 960H DVR Support LOOP Output, 8*4 TB HDD, P2P Function

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C, Western Union or MoneyGram

Product Description

Video compression: H.264

Video system: PAL/NTSC

Operation system: Linux (embedded)

32CH input /2CH output(BNC)

16CH input /2CH output(BNC)

16CH loop out

Display resolution:

Display features:

Record resolution:

Record speed:

Recording mode: Continuous/manual/motion detect /sensor/alarm recording

Playback channel: 1/4/9/16ch

Sensor & alarm I/O: 16ch sensor input, 4 channel alarm out

IR extender port: Yes

HDD interface: 8 SATA HDDs, each HDD max up to 4TB

PTZ control: Built in RS485, support Pelco-P & Pelco-D

Mobile surveillance: Supports mobile phones based on Windows mobile, Symbian, iPhone, Blackberry and Android operation system

VGA: 800*600, 1,024*768, 1,280*1,024, 1,440*900 and 1,920*1,080

HDMI: 1,080P

Loop: 16CH loop out

Power supply range: AC 100~240V/5.0A,50~60Hz

PAL: 960×576@25fps (each ch, frame)

NTSC: 960×480@30fps (each ch, frame)

Single/quad/nine/sixteen/rhirty-two S.E.Q.

PAL:D1 360×288 (CIF), 720x288 (HD1), 720x576 (D1)

960H: 480×288 (WCIF), 960×288 (WHD1), 960×576 (WD1)

NTSC:D1: 360×240 (CIF), 720x240 (HD1), 720x480 (D1)

960H: 480×240 (WCIF), 960×240 (WHD1), 960×480 (WD1)

PAL: D1 mode/960H mode:25fps, NTSC D1mode/960H mode 30fps

PAL: D1mode/960H mode 25fps NTSC D1mode/960Hmode 30fps
