LED Intelligent Control Card with 7-inch, High-resolution, Multifunction

Get Latest Price

Payment Type:: Telegraphic Transfer (TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

Specifications:

Display size: 7.0 inches
Aspect ratio: 16:9
Dimensions (W x H x D): 165 x 104 x 5.7mm
Viewing angle: 35/50/55/55 degrees
Resolution (H x V): 480 x RGB x 234 pixels
Contrast ratio: 250:1
Brightness: 200cd/m²
Interface type: single 26-pin
Backlight: LEDs
Response time: 30ms
Working temperatures: -20-80℃
UT-A72-N1 V1.1 driver board using mature MSTAR720 program, vivid display
Production is widely used in instrumentation, industrial control, medical equipment, video intercom, security monitoring, car, bank notes and acceptance device, supermarket cashier, and many other occasions
CVBS1, CVBS2, S-Video (optional) video signal input
Multi OSD operating
With remote control (optional)
Startup, shutdown status indicator (green for power, red for the shutdown)

Display size: 7.0 inches

Aspect ratio: 16:9

Dimensions (W x H x D): 165 x 104 x 5.7mm

Viewing angle: 35/50/55/55 degrees

Resolution (H x V): 480 x RGB x 234 pixels

Contrast ratio: 250:1

Brightness: 200cd/m²

Interface type: single 26-pin

Backlight: LEDs

Response time: 30ms

Working temperatures: -20-80℃

UT-A72-N1 V1.1 driver board using mature MSTAR720 program, vivid display

Production is widely used in instrumentation, industrial control, medical equipment, video intercom, security monitoring, car, bank notes and acceptance device, supermarket cashier, and many other occasions

CVBS1, CVBS2, S-Video (optional) video signal input

Multi OSD operating

With remote control (optional)

Startup, shutdown status indicator (green for power, red for the shutdown)
