LED Display with 1R1G1B DIP, 10mm Pixel Pitch and 70 to 80Hz Frame Frequency

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

Pixel pitch: 10mm

DIP: 1R1G1B

Pixel construction: 1 red chip, 1 green chip and 1 blue chip(1R1G1B)

Module resolution (L x H): 16 x 16mm, 256 pixel dots

Brightness of white: 6,500cd/m² at least

Optimal viewing distance: 8 to 75m

Grey scale: 10-bit/1,024-level

Display color: 1,024 x 1,024 x 1,024, 1 billion

Viewing angle: 100/45°

Refresh rate: 400Hz at least

Driving mode: constant driving 1/4 scan

Brightness adjustment: 0, 100% with 8 levels automatic

Gamma correction: -5.0 to 5.0

Correction scale level: 16 bits

Frame frequency: 70 to 80Hz

Color temperatures: 5,000 to 9,300K (control by thesoftware)

Input source supports: S-video/VGA/DVI/SDI/HD-SDI

Lifetime: 100,000 hours at least

MTBF: 5,000 hours at least

Out of control rate: 3/10,000 at most
