SMD 3-in-1 LED Display Sign/Screen with P8 Pixel Pitch and 5,000 to 9,300K Color Temperature

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T

Product Description

Pixel pitch: 8mm

SMD 3-in-1 function

Pixel construction: one chip with 3 color (3-in-1)

Module resolution (L x H): 32 x 16mm = 512 pixels/dots

Brightness of white: 1,500cd/m² at least

The optimal viewing distance: 5 to 38m

Grey scale: 10-bits/1,024-levels

Display color: 1,024 x 1,024 x 1,024 = 1 billion

Viewing angle:

Refresh rate: 240Hz at least

Driving mode: constant driving 1/8 scan

Brightness adjustment: 0 to 100% with 8 levels automatic

Gamma correction: -5.0 to 5.0

Correction scale level: 16bits

Frame frequency: 60 to 85Hz

Color temperature: 5,000 to 9,300K (control by thesoftware)

Input source support: S-video/VGA/DVI/SDI/HD-SDI

Lifespan: 100,000 hours at least

MTBF: 5,000 hours at least

Out of control rate: 3/10,000 at most

Horizontal: 150 degrees

Vertical: 120 degrees
