P4 LED Display with SMD 3-in-1, 16-bit Correction Scale Level, 60 to 85Hz Frame Frequency, 4mm Pitch

Get Latest Price

Payment Type:: Telegraphic Transfer (TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

Specifications:

Pixel pitch: 4mm
Resolution: 32 x 32 pixels
Size: 128 x 128mm
Pixel configuration: 3-in-1
Density: 62,500 dots/m²

Main technical parameters:

Best viewing distance: 2 to 20m
Best viewing angle:
- Horizontal: 150°
- Vertical: 120°
Brightness: e2,500cd/m²
Drive mode: constant driving and 1/6 scan
Exchange frame frequency: e72Hz
Refresh rate: e240Hz
Grey grade: 1,024 levels
Protection rate: IP43
Control mode: synchronization
Working voltage: 220V AC/380V ± 10%, 50Hz
Maximum power consumption: 2,000W/sqm
Working environment temperature: -20 to +50°C
Screen lifespan: e100,000 hours
Blind DOT rate: below 0.0001
Computer operating system: Microsoft's Windows 98, XP, 2000 andmore
Video signals: RF, S-Video, RGB, RGBHV, YUV and more
Control system: DVI graphics card + sending card + receivingcard
Software: LED studio
With CE, RoHS, FCC marks

All trademarks shown here are for reference purposesonly. They are the property of their respective owners, and we arenot authorized to sell items bearing such trademarks.

Pixel pitch: 4mm

Resolution: 32 x 32 pixels

Size: 128 x 128mm

Pixel configuration: 3-in-1

Density: 62,500 dots/m²

Best viewing distance: 2 to 20m

Best viewing angle:

Horizontal: 150°
Vertical: 120°

Brightness: e2,500cd/m²

Drive mode: constant driving and 1/6 scan

Exchange frame frequency: e72Hz

Refresh rate: e240Hz

Grey grade: 1,024 levels

Protection rate: IP43

Control mode: synchronization

Working voltage: 220V AC/380V ± 10%, 50Hz

Maximum power consumption: 2,000W/sqm

Working environment temperature: -20 to +50°C

Screen lifespan: e100,000 hours

Blind DOT rate: below 0.0001

Computer operating system: Microsoft's Windows 98, XP, 2000 andmore

Video signals: RF, S-Video, RGB, RGBHV, YUV and more

Control system: DVI graphics card + sending card + receivingcard

Software: LED studio

With CE, RoHS, FCC marks

Horizontal: 150°

Vertical: 120°
