LED Display with SMD 3-in-1, 7.62mm Pixel Pitch and 1,500 Nits Brightness

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Specifications:

Main technical parameters:

Pixel pitch: 7.62mm

Resolution: 32 x 16 pixels

Module size: 244 x 122

Pixel configuration: 3-in-1

Density: 17,222 dots/m²

2 cabinet parameters

Cabinet size: 976 x 732mm

Cabinet resolution: 128 x 96

Module quality: 4 x 6 pieces

LED standard: 3528 SMD

Viewing distance: 5 to 38m

Viewing angles:

Brightness: ≥1,500CD/m²

Drive mode: constant driving, 1/8 scan

Exchange frame frequency: ≥60Hz

Refresh rate: 350Hz

Gray grade: 1,024 levels

Protection rate: ≥13

Control mode: synchronization

Working voltage: 220/380V AC ±10, 50Hz

Power consumption: 800W/m² (maximum)

Working environment temperature: -20 to 50°C

Screen lifespan: ≥100,000 hours

Operating systems: Microsoft's Windows 98, XP, 2000 and more

Video signal: RF, S-video, RGB, RGBHV, YUV and more

Control system: DVI graphics card + sending card + receiving card

Software: LED studio

With CE and FCC marks

Compliant with the RoHS Directive

Horizontal: 150°

Vertical: 120°
