P6 LED Display Screen, 3-in-1 SMD, Most Popular Indoor Type

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Features:

Pixel pitch: 6mm

Encapsulation: 3528 SMD

Module resolutions (L x H): 32 x 16mm = 512 pixel dots

Pixel density: 27,777 pixel dots/m²

Brightness of white: 2,000cd/m² at least

Optimal viewing distances: 3 to 38m

Grayscale: 8 bits/256 levels

Display colors: 256 x 256 x 256 (16 million)

Viewing angles (H/V): 150/120°

Refresh rate: 240Hz at least

Driving mode: constant driving 1/8 scan

Protection degrees: IP65

Color temperatures: 5,000 to 9,300K

Average power consumption: 500W/m²

Maximum power consumption: 1,200W/m²

Input source supports: S-Video/VGA/DVI/SDI/HD-SDI

Lifetime: 100,000 hours at least

MTBF: 5,000 hours at least

Out of control rates: 3/10,000 at most

Working temperatures: -20 to 60°C

Working humidity range: 10 to 95% RH
