P20 LED Display/Screen/Sign, DIP 2R/1G/1B, 16 x 8mm Module Resolution, 400Hz Refresh Rate

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Specifications:

Pixel pitch: 20mm

DIP 2R/1G/1B

Pixel construction: 2 red chips, 1 green and blue chip(2R/1G/1B)

Module resolution (L x H): 16 x 8mm, =128 pixels dots

Brightness of white: 6,500cd/m²

Optimal viewing distance: 20 to 160m

Grey scale: 10-bit/1,024-level

Display color: 1,024 x 1,024 x 1,024 =1 billion

Viewing angle (H/V): 100/45°

Refresh rate: 400Hz

Driving mode: static latch

Brightness adjustment: 0 to 100% with 8 levels automatic

Gamma correction: -5 to 5

Correction scale level: 16 bits

Frame frequency: 60 to 85Hz

Color temperature: 5,000 to 9,300K (control by thesoftware)

Input source support: S-video/VGA/DVI/SDI/HD-SDI

Lifespan: 100,000 hours

MTBF: 5,000 hours
