ESD Diode, Electrostatic Discharge Protection for Consumer Electronics

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Description:

The ULC0568M is designed to protect voltage sensitive components from ESD and transient voltage events. Excellent clamping capability, low leakage, and fast response time, make these parts ideal for ESD protection on designs where board space is at a premium

Features:

125W peak pulse power per line (tp=8/20μs)
Protects four I/O lines and one Vcc line
Low capacitance
Working voltages: 5V
Low leakage current
IEC61000-4-2 (ESD) ±15kV (air), ±8kV (contact)
IEC61000-4-4 (EFT) 40A (5/50ηs)
IEC61000-4-5 (Lightning) 5A (8/20μs)

Applications:

High Definition Multi-Media Interface (HDMI)
Digital Visual Interface (DVI)
10/100/1000 Ethernet
Monitors and flat panel displays
Notebook computers
Set-top box
Projection TV

Mechanical characteristics:

MSOP-10 package
Molding compound flammability rating : UL 94V-0
Weight 12.0 milligrams (approximate)
Quantity per reel : 1,000pcs
Reel size: 7 inches
Lead finish: lead-free

The ULC0568M is designed to protect voltage sensitive components from ESD and transient voltage events. Excellent clamping capability, low leakage, and fast response time, make these parts ideal for ESD protection on designs where board space is at a premium

125W peak pulse power per line (tp=8/20μs)

Protects four I/O lines and one Vcc line

Low capacitance

Working voltages: 5V

Low leakage current

IEC61000-4-2 (ESD) ±15kV (air), ±8kV (contact)

IEC61000-4-4 (EFT) 40A (5/50ηs)

IEC61000-4-5 (Lightning) 5A (8/20μs)

High Definition Multi-Media Interface (HDMI)

Digital Visual Interface (DVI)

10/100/1000 Ethernet

Monitors and flat panel displays
