ESD Diode, Electrostatic Discharge Protection, SOP-16

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Description:

LCDAxxC-8 has been specifically designed to protect sensitive components which are connected to data and transmission lines from over voltages caused by electrostatic discharge (ESD), electrical fast transients (EFT) and lightning
Low capacitance array configuration of LCDAxxC-8 allows user to protect eight high speed data or I/O lines
They may be used on systems operating from 5 to 24V
High surge capability (500W, tp=8/20μs) makes LCDAxxC-8 suitable for telecommunications systems operating in harsh transient environments
Low inductance construction minimizes voltage overshoot during high current surges
Features of LCDAxxC-8 are ideal for protecting multi-protocol transceivers in WAN applications such as frame relay systems, routers and switches

Features:

500W peak pulse power per line (tp=8/20μs)
Protects eight I/O lines
Low capacitance for high speed data lines
RoHS Directive-compliant
IEC61000-4-2 (ESD): ±15kV (air) and ±8kV (contact)
IEC61000-4-4 (EFT): 40A (5/50ηs)
IEC61000-4-5 (lightning): 24A (8/20μs)

Applications:

High speed data lines
Microprocessor based equipment
Test and measurement equipment
Notebooks, desktops and servers
Instrumentation
Audio/video inputs
LAN/WAN equipment
Peripherals

Mechanical characteristics:

JEDEC SOP-16 packing
Molding compound flammability rating: UL 94V-0
Weight: 150.0mg (approximately)
Quantity: 500 pieces/reel
Reel size: 7-inch
Lead finish: lead-free

LCDAxxC-8 has been specifically designed to protect sensitive components which are connected to data and transmission lines from over voltages caused by electrostatic discharge (ESD), electrical fast transients (EFT) and lightning

Low capacitance array configuration of LCDAxxC-8 allows user to protect eight high speed data or I/O lines

They may be used on systems operating from 5 to 24V

High surge capability (500W, tp=8/20μs) makes LCDAxxC-8 suitable for telecommunications systems operating in harsh transient environments

Low inductance construction minimizes voltage overshoot during high current surges

Features of LCDAxxC-8 are ideal for protecting multi-protocol transceivers in WAN applications such as frame relay systems, routers and switches

500W peak pulse power per line (tp=8/20μs)

Protects eight I/O lines

Low capacitance for high speed data lines

RoHS Directive-compliant

IEC61000-4-2 (ESD): ±15kV (air) and ±8kV (contact)

IEC61000-4-4 (EFT): 40A (5/50ηs)

IEC61000-4-5 (lightning): 24A (8/20μs)
