ESD Electrostatic Discharge Protection, SOT-323
  • ESD Electrostatic Discharge Protection, SOT-323
ESD Electrostatic Discharge Protection, SOT-323

ESD Electrostatic Discharge Protection, SOT-323

Get Latest Price
Payment Type:
Telegraphic Transfer in Advance (Advance TT, T/T)
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: Telegraphic Transfer in Advance (Advance TT, T/T)
Product Description
Product Description
  • Descriptions:
    • The ESD05V32T-2A is designed to protect voltage sensitive components from ESD and transient voltage events
    • Good clamping capability, low leakage, and fast response time, make these parts ideal for ESD protection on designs where board space is at a premium
  • Features:
    • 100W peak pulse power per line (tp=8/20μs)
    • Protects two lines in common mode or one line in differential mode
    • Low clamping voltage
    • Working voltage: 5.0V
  • Low leakage current:
    • IEC61000-4-2 (ESD) ±25kV (air), ±15kV (contact)
    • IEC61000-4-4 (EFT) 40A (5/50ηs)
    • IEC61000-4-5 (lightning) 5A (8/20μs)
  • Applications:
    • Cellular handsets and accessories
    • High-speed I/O lines
    • USB ports
    • Serial ATA
    • PCI express
    • Servers, notebook, and desktop PC
    • Display ports
  • Mechanical characteristics:
    • SOT-323 package
    • Molding compound flammability rating: UL94V-0
    • Weight 6.0 milligrams (approximate)
    • Quantity per reel: 3,000pcs
    • Reel size: 7 inches
    • Lead finish: lead-free
  • The ESD05V32T-2A is designed to protect voltage sensitive components from ESD and transient voltage events
  • Good clamping capability, low leakage, and fast response time, make these parts ideal for ESD protection on designs where board space is at a premium
  • 100W peak pulse power per line (tp=8/20μs)
  • Protects two lines in common mode or one line in differential mode
  • Low clamping voltage
  • Working voltage: 5.0V
  • IEC61000-4-2 (ESD) ±25kV (air), ±15kV (contact)
  • IEC61000-4-4 (EFT) 40A (5/50ηs)
  • IEC61000-4-5 (lightning) 5A (8/20μs)
  • Cellular handsets and accessories
  • High-speed I/O lines
  • USB ports
  • Serial ATA
  • PCI express
  • Servers, notebook, and desktop PC
  • Display ports
  • SOT-323 package
  • Molding compound flammability rating: UL94V-0
  • Weight 6.0 milligrams (approximate)
  • Quantity per reel: 3,000pcs
  • Reel size: 7 inches
  • Lead finish: lead-free
