ESD Array, Electrostatic Discharge Protection, MSOP-08
  • ESD Array, Electrostatic Discharge Protection, MSOP-08
ESD Array, Electrostatic Discharge Protection, MSOP-08

ESD Array, Electrostatic Discharge Protection, MSOP-08

Get Latest Price
Payment Type:
Telegraphic Transfer in Advance (Advance TT, T/T)
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: Telegraphic Transfer in Advance (Advance TT, T/T)
Product Description
Product Description
  • Description: the ULC0568M is designed to protect voltage sensitive components from ESD and transient voltage events. Good clamping capability, low leakage, and fast response time, make these parts ideal for ESD protection on designs where board space is at a premium
  • Features:
    • 100W peak pulse power per Line (tp=8/20μs)
    • Protects six high-speed I/O lines
    • Low clamping voltage
    • Working voltage: 5V
    • Low leakage current
    • IEC61000-4-2 (ESD) ±15kV (air), ±8kV (contact)
    • IEC61000-4-4 (EFT) 40A (5/50ηs)
    • IEC61000-4-5 (Lightning) 3A (8/20μs)
  • Mechanical characteristics:
    • MSOP-08 package
    • Molding compound flammability rating: UL 94V-0
    • Weight: 25.0 milligrams (approximate)
    • Quantity per reel: 1,000pcs
    • Reel size: 7 inches
    • Lead finish: lead-free
  • Applications:
    • USB series or high-speed data line
    • Microprocessor based equipment
    • Video graphs cards
    • Digital Video Interface (DVI)
    • High Definition Multi-Media Interface (HDMI)
    • ATM interfaces
    • IEEE1394 fire wire ports
  • 100W peak pulse power per Line (tp=8/20μs)
  • Protects six high-speed I/O lines
  • Low clamping voltage
  • Working voltage: 5V
  • Low leakage current
  • IEC61000-4-2 (ESD) ±15kV (air), ±8kV (contact)
  • IEC61000-4-4 (EFT) 40A (5/50ηs)
  • IEC61000-4-5 (Lightning) 3A (8/20μs)
  • MSOP-08 package
  • Molding compound flammability rating: UL 94V-0
  • Weight: 25.0 milligrams (approximate)
  • Quantity per reel: 1,000pcs
  • Reel size: 7 inches
  • Lead finish: lead-free
  • USB series or high-speed data line
  • Microprocessor based equipment
  • Video graphs cards
  • Digital Video Interface (DVI)
  • High Definition Multi-Media Interface (HDMI)
  • ATM interfaces
  • IEEE1394 fire wire ports
