TVS Diodes, SOD123
- Payment Type:
- T/T in Advance
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Payment Type: | T/T in Advance |
|---|
Product Description
Product Description
- Designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events
- Suitable for surface-mounted applications in order to optimize board space
- Low leakage
- Uni and bidirectional unit
- Glass passivate junction
- Low inductance
- Nice clamping capability
- 200W peak power capability at 10 x 1000µs waveform
- Repetition rate (duty cycle): 0.01%
- Fast response time: typically less than 1.0ps from 0V to VBR (minimum)
- Typical IR less than 5μA above 12V
- High temperature soldering: 260°C/40 seconds at terminals
- Typical maximum temperature coefficient ΔVBR = 0.1% x VBR at 25°C x ΔT
- Plastic package has underwriters laboratory flammability 94V-0
- Matte tin lead-free plating
- Halogen-free
- RoHS Directive-compliant
- Typical failure mode is short from over-specified voltage or current
- Whisker test is conducted based on JEDEC JESD201A per its table 4a and 4c
- IEC 61000-4-2 (ESD): 15 (air) and 8kV (contact)
- ESD protection of data lines in accordance with IEC 61000-4-2 (IEC 801-2)
- EFT protection of data lines in accordance with IEC 61000-4-4 (IEC 801-4)
- Ideal for protection of I/O interfaces, VCC bus and other vulnerable circuits
- Used in telecom, computer, industrial and consumer electronic applications
