Transflective FSTN LCD Display with 1/240 Duty, 1/6 Bias, High Contrast and Wide Temperature Range

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Cash in Advance (CID

Product Description

Consists of 320 x 240 dot-matrix

LCD and LCD driver on a single PCB and white LED

LCD type: FSTN

Polarizer type: transflective/positive

Viewing direction: 6:00Interface: parallel

Number of dots: 320 x 240

Dot size (W×H): 0.225 x 0.225mm

Dot pitch (W×H): 0.24 x 0.24mm

Active area (W X H): 76.785 × 57.585mm

Viewing area (W X H): 79.8 × 60.6

Outline dimensions (W x H x D): 91.5 × 75.0 × 6.6mm

LCD controller and driver: ST8016

LCD driving method: 1/240 duty, 1/6 bias

Backlight type: LED

Backlight color: white

Operating temperatures: -20 to 70°C

Storage temperatures: -30 to 80°C
