Indoor Antenna with 50W Maximum Power and 806 to 960/1,710 to 2,500MHz Frequency Range
  • Indoor Antenna with 50W Maximum Power and 806 to 960/1,710 to 2,500MHz Frequency Range
Indoor Antenna with 50W Maximum Power and 806 to 960/1,710 to 2,500MHz Frequency Range

Indoor Antenna with 50W Maximum Power and 806 to 960/1,710 to 2,500MHz Frequency Range

Get Latest Price
Payment Type:
TT, Western Union, L/C at Sight, PayPal
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: TT, Western Union, L/C at Sight, PayPal
Product Description
Product Description
  • Applied to base stations, indoor coverage systems and GSM/CDMA/PCS/3G/WLAN systems
  • Electrical specifications:
    • Frequency range: 806 to 960/1,710 to 2,500MHz
    • Bandwidth: 154/790MHz
    • Gain: 3/5dBi
    • Vertical beam widths: 120/120
    • Horizontal beam width: 360/120
    • VSWR: 1.5
    • Nominal impedance: 50
    • Polarization: vertical
    • Maximum power: 50W
    • Connector: N-K
  • Mechanical specifications:
    • Cable length: 0.3m
    • Antenna dimensions: 187 x 86 x 18mm
    • Weight: 198g
    • Temperature range: -40 to 60
    • Humidity range: 5 to 95%
    • Installation way: ceiling mount
  • Frequency range: 806 to 960/1,710 to 2,500MHz
  • Bandwidth: 154/790MHz
  • Gain: 3/5dBi
  • Vertical beam widths: 120/120
  • Horizontal beam width: 360/120
  • VSWR: 1.5
  • Nominal impedance: 50
  • Polarization: vertical
  • Maximum power: 50W
  • Connector: N-K
  • Cable length: 0.3m
  • Antenna dimensions: 187 x 86 x 18mm
  • Weight: 198g
  • Temperature range: -40 to 60
  • Humidity range: 5 to 95%
  • Installation way: ceiling mount
