Terminal Panel Antenna with 689-960/1,710-2,500MHz Frequency and 10dBi Gain
  • Terminal Panel Antenna with 689-960/1,710-2,500MHz Frequency and 10dBi Gain
Terminal Panel Antenna with 689-960/1,710-2,500MHz Frequency and 10dBi Gain

Terminal Panel Antenna with 689-960/1,710-2,500MHz Frequency and 10dBi Gain

Get Latest Price
Payment Type:
T/T, Western Union, L/C at Sight, PayPal
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T, Western Union, L/C at Sight, PayPal
Product Description
Product Description
  • Description:
    • It's applied to base station, indoor coverage system and GSM/CDM/PCS/3G/WLAN system
  • Specifications:
    • Electrical:
      • Frequency range: 689 to 960/1,710 to 2,500MHz
      • Bandwidth: 154/790MHz
      • Gain: 10dBi
      • VSWR: ≤1.5
      • Nominal impedance: 50Ω
      • Polarization: vertical
      • Maximum power: 50W
      • Connector: NK
    • Mechanical:
      • Cable length: 0.5m
      • Antenna dimension: 135 x 89 x 112mm x M18
      • Weight: 308g
      • Temperatures: -40 to 60°C
      • Humidity range: 5 to 95%
      • Installation way: ceiling mount
  • It's applied to base station, indoor coverage system and GSM/CDM/PCS/3G/WLAN system
  • Electrical:
    • Frequency range: 689 to 960/1,710 to 2,500MHz
    • Bandwidth: 154/790MHz
    • Gain: 10dBi
    • VSWR: ≤1.5
    • Nominal impedance: 50Ω
    • Polarization: vertical
    • Maximum power: 50W
    • Connector: NK
  • Mechanical:
    • Cable length: 0.5m
    • Antenna dimension: 135 x 89 x 112mm x M18
    • Weight: 308g
    • Temperatures: -40 to 60°C
    • Humidity range: 5 to 95%
    • Installation way: ceiling mount
  • Frequency range: 689 to 960/1,710 to 2,500MHz
  • Bandwidth: 154/790MHz
  • Gain: 10dBi
  • VSWR: ≤1.5
  • Nominal impedance: 50Ω
  • Polarization: vertical
  • Maximum power: 50W
  • Connector: NK
  • Cable length: 0.5m
  • Antenna dimension: 135 x 89 x 112mm x M18
  • Weight: 308g
  • Temperatures: -40 to 60°C
  • Humidity range: 5 to 95%
  • Installation way: ceiling mount
