Built-in GPS Antenna with 20MHz Bandwidth and UFL Connector, Measures 25 x 25 x 4mm
  • Built-in GPS Antenna with 20MHz Bandwidth and UFL Connector, Measures 25 x 25 x 4mm
Built-in GPS Antenna with 20MHz Bandwidth and UFL Connector, Measures 25 x 25 x 4mm

Built-in GPS Antenna with 20MHz Bandwidth and UFL Connector, Measures 25 x 25 x 4mm

Get Latest Price
Payment Type:
PayPal, L/C, Western Union or T/T
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: PayPal, L/C, Western Union or T/T
Product Description
Product Description
  • Center frequency: 1,575.42 ± 1MHz
  • Output VSWR: <2.0
  • Band width: 20MHz
  • Impedance: 50Ω
  • Polarization: RHCP
  • LNA gain (without cable): 30 ± 2dB type (3.3 to 5V)
  • Noise figure: <2dB at 3.3V (maximum)
  • DC voltages: 3.3 to 5V
  • DC current: 50mA (maximum)
  • Work power: 300mW (minimum) and 1.5W (maximum)
  • Weight: 73g
  • Dimensions: 25 x 25 x 4mm
  • Cable: IPEX1.13
  • Connector: UFL
  • Mounting: magnetic base
  • Housing: black matte surface
  • Working temperatures: -40 to 85°C
  • Humidity range: 95 to 100% RH
  • Weatherproof protection grade: IP67
