DALI Bus Dimming LED Driver with 3 to 50V DC Voltage

DALI Bus Dimming LED Driver with 3 to 50V DC Voltage

Get Latest Price

Payment Type:: T/T in Advance

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T in Advance

Product Description

Features:

It can vary the light intensity of the LED loading by means of a DALI Bus control signal, AC push button, which can use the normal wall mount AC switch to modify
Wide range of output voltage, 3 to 50V DC, can power 1 to 14 pieces of 1W high-power LEDs or 1 to 8 pieces of 3W high-power LEDs, also suitable for COB and LED strip
Universal input voltage: 90 to 264V AC, 50/60Hz
Output current: multi-current can select, set output current by dip switch (300, 350, 450, 500, 650, 700mA)
Built-in active PFC
High-efficiency up to 85%
Protections: short-circuit with hiccup mode, overload
Natural air convection
Class II, no FG
Plastic case, IP20 for indoor use only
Optional multiple dim functions suitable for LED lighting application
High-current accuracy to make LED lifespan longer
2-year warranty

Dimming functions:

DALI Bus dimming
1 to 10V dc dimming
Ext. Pot. dimming

It can vary the light intensity of the LED loading by means of a DALI Bus control signal, AC push button, which can use the normal wall mount AC switch to modify

Wide range of output voltage, 3 to 50V DC, can power 1 to 14 pieces of 1W high-power LEDs or 1 to 8 pieces of 3W high-power LEDs, also suitable for COB and LED strip

Universal input voltage: 90 to 264V AC, 50/60Hz

Output current: multi-current can select, set output current by dip switch (300, 350, 450, 500, 650, 700mA)

Built-in active PFC

High-efficiency up to 85%

Protections: short-circuit with hiccup mode, overload

Natural air convection

Class II, no FG

Plastic case, IP20 for indoor use only

Optional multiple dim functions suitable for LED lighting application

High-current accuracy to make LED lifespan longer

2-year warranty

DALI Bus dimming
