OTP/Optical Touch Screen Overlay, 21.5-inch, 493x291mm Panel Frame SizeNew

OTP/Optical Touch Screen Overlay, 21.5-inch, 493x291mm Panel Frame SizeNew

Get Latest Price

Payment Type:: T/T in Advance

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T in Advance

Product Description

Specifications:

Panel size: 21.5-inch, suitable for 21.5-inch LCD or another screen
Panel frame size: 493 x 291mm
Touch area: 500 x 299mm
Board size: 70 x 45 x 4.2mm include component
Certification: Microsoft's Windows touch digitizer WHQL test
Minimum touch object: stylus minimum diameter 2mm
Input method: finger, gloved hand, or any other pointer
Response time: <10ms
Resolution: 32,767 x 32,767P
Accuracy: more than 95% of the area is ±2mm
Glass: steel processing, thickness 1.85 ±0.15mm
Touch times: unlimited
Glass transmittance: >88%, average
Module weight: 700g ±8%
Cursor speed: 120 dots/second
Linearity error: <5mm
Interface: USB HID multi-touch digitizer (plug-and-play function without driver)
Operating system: Microsoft's Windows 7, 8, XP, Vista, Linux, Apple's Mac OS, Android
Effective touch: 420.4 x 273.1mm
Operating current: 500mA
USB power requirements: 2.5W standard USB power 5V DC ±5%, 500mA
Operating temperature: 0-50°C
Storage range: -30-65°C, 0-90% RH

Applications:

Kiosks, ATM, exhibitions, education and trainings, business offices, advertising, media, game consoles, interactive advertising, medical equipment Industrial, multiple medias inquiries, POS machines, automatic ticketing, self-service retails, public receptions, government applications securities military use, interactive whiteboard

Panel size: 21.5-inch, suitable for 21.5-inch LCD or another screen

Panel frame size: 493 x 291mm

Touch area: 500 x 299mm

Board size: 70 x 45 x 4.2mm include component

Certification: Microsoft's Windows touch digitizer WHQL test

Minimum touch object: stylus minimum diameter 2mm

Input method: finger, gloved hand, or any other pointer

Response time: <10ms

Resolution: 32,767 x 32,767P

Accuracy: more than 95% of the area is ±2mm

Glass: steel processing, thickness 1.85 ±0.15mm

Touch times: unlimited

Glass transmittance: >88%, average

Module weight: 700g ±8%

Cursor speed: 120 dots/second

Linearity error: <5mm

Interface: USB HID multi-touch digitizer (plug-and-play function without driver)

Operating system: Microsoft's Windows 7, 8, XP, Vista, Linux, Apple's Mac OS, Android

Effective touch: 420.4 x 273.1mm

Operating current: 500mA

USB power requirements: 2.5W standard USB power 5V DC ±5%, 500mA

Operating temperature: 0-50°C

Storage range: -30-65°C, 0-90% RH

Kiosks, ATM, exhibitions, education and trainings, business offices, advertising, media, game consoles, interactive advertising, medical equipment Industrial, multiple medias inquiries, POS machines, automatic ticketing, self-service retails, public receptions, government applications securities military use, interactive whiteboard
