1-layer 142.23 x 132.1mm Single-sided PCB with 1.6mm Board Thickness and Immersion Finish

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, OA, PayPal

Product Description

1-layer single-sided PCB made of FR4, 142.23 x 132.1mm unit size, 1.6mm board thickness and immersion finish

Capability:

Layer: 1 to 28
Board finished thickness: 0.21 to 7.0mm
Material: FR-4, CEM-1, CEM-3, high TG, FR4 halogen free and Rogers
Maximum finished board size: 23 x 25mm (580 x 900mm)
Minimum drilled hole size: 3mil (0.075mm)
Minimum line width: 3mil (0.075mm)
Minimum line spacing: 3mil (0.075mm)
Surface finish/treatment: HASL/HASL lead-free, HAL, chemical tin, chemical gold, immersion silver/gold, OSP and gold plating
Copper thickness: 0.5 to 7.0oz
Solder mask color: green/yellow/black/white/red/blue
Copper thickness in hole: >25.0μm (>1mil)
Inner packing: vacuum packing/plastic bag
Outer packing: standard carton packing
Shape tolerance: ±0.13
Hole tolerance:
- PTH: ±0.076
- NPTH: ±0.05
UL pending
Special requirements: buried and blind vias, controlled impedance and BGA
Profiling: punching, routing, V-cut and beveling
