Single-sided PCB with Made of FR4 TG-170 Material, 2.0mm Thickness, 1oz Copper, OSP Surface Finish

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Material: FR4 TG-170

Copper: 1oz

Board thicknesses: 2.0mm

Size: 289 x 124mm/2 pieces

Minimum hole size: 0.26mm

Minimum line width/space: 0.24/0.16mm, ENIG

Capability:

Layer: 1 to 28
Board finished thickness: 0.21 to 7.0mm
Material: FR-4, CEM-1, CEM-3, high TG, FR4 halogen free androgers available
Finished board size: 580 x 900mm (maximum)
Drilled hole size: 3 mils (0.075mm) (minimum)
Line width: 3 mils (0.075mm) (minimum)
Line spacing: 3 mils (0.075mm) (minimum)
Surface finish/treatment: HASL/HASL lead free, HAL, chemicaltin, chemical gold, immersion silver/gold, OSP and goldplating
Copper thickness: 0.5 to 7.0oz
Solder mask color: green/yellow/black/white/red/blue
Copper thickness in hole: >25.0μm (>1 mil)
Inner packing: vacuum packing/plastic bag
Outer packing: standard carton packing
Shape tolerance: ±0.13mm
Hole tolerance:
PTH: ±0.076mm
NPTH: ±0.05mm
