Double-sided PCB, with Red Solder Mask Golden Fingers and HASL Lead-free Finish

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Double-sided PCB with red solder mask golden fingers

Material: FR-4

Layers: 2

Copper thickness: 1oz

Solder mask: red

Silkscreen: white

Surface finish: HASL lead free

Buried and blind hole: not supported

Applications: gas detectors, remote controls, andtelecommunication products

Layers: 1 to 28

Board finished thickness: 0.21 to 7.0mm

Materials: FR-4, CEM-1, CEM-3, high TG, FR4 halogen-free, andRogers

Maximum finished board size: 23 x 25 (580 x 900mm)

Minimum drilled hole size: 3mil (0.075mm)

Minimum line width: 3mil (0.075mm)

Minimum line spacing: 3mil (0.075mm)

Surface finish/treatment: HASL/HASL lead-free, HAL, chemicaltin, chemical gold, immersion silver, gold, OSP, and goldplating

Copper thickness: 0.5 to 7.0oz

Solder mask color: green, yellow, black, white, red, andblue

Copper thickness in hole: >25.0um (>1mil)

Inner packing: vacuum packing and plastic bag

Outer packing: standard carton packing

Shape tolerance: ±0.13

Hole tolerance:

PTH: ±0.076
NPTH: ±0.05

Certificate: UL

Special requirements: buried and blind vias, controlledimpedance and BGA

Profiling: punching, routing, V-cut, and beveling

OEM orders are welcomed

Disclaimer: All trademarks shown here are for referencepurposes only. They are the property of their respective owners,and we are not authorized to sell items bearing suchtrademarks.

PTH: ±0.076

NPTH: ±0.05
