Electric Motor, FC-140PA, with Rated Voltage of 12V, for Vehicle
  • Electric Motor, FC-140PA, with Rated Voltage of 12V, for Vehicle
Electric Motor, FC-140PA, with Rated Voltage of 12V, for Vehicle

Electric Motor, FC-140PA, with Rated Voltage of 12V, for Vehicle

Get Latest Price
Payment Type:
T/T, L/C, Western Union, Cash, PayPal or MoneyGram
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T, L/C, Western Union, Cash, PayPal or MoneyGram
Product Description
Product Description
  • Key features:
    • Plastic end cap
    • Oil-impregnated bearing
    • Leaf brush system
    • Carbon steel shaft
  • Dimensions:
    • Diameter: 20.2mm
    • Length: 25mm
    • Height: 15.4mm
    • Shaft: could be made according to your demand
  • Technical data:
    • Voltage:
      • Operating voltage: 6.0-12.0V
      • Rated voltage: 12.0V
    • No load:
      • Speed: 30000rpm
      • Current: 0.32A
    • At max efficiency:
      • Speed: 24370rpm
      • Current: 1.39A
      • Torque: 3.9mNm
      • Output: 9.86W
      • Efficiency data: 60%
      • Stall torque: 20.6mNm
      • Stall current: 6.0A
      • Direction of rotation: CW/CCW
    • Note: all of the technical data could be custom made
  • Typical applications:
    • Rear-view mirror
    • Headlamp adjuster
    • Mirror adjuster
    • RC model/toy
  • Constructions of motor:
    • 2-pole stator
    • Sr ferrite permanent magnet
    • 3, 5, 7, 8, 9, 12 slots armature
    • Silicon-steel lamination with epoxy coating
    • High-carbon steel shaft
    • Cu-Ag alloys commutator
    • Copper-graphite brushes
    • Be-Cu leaf-brush commutating system
    • SECD round/flat shape housing
    • SECD end cap/PA66 + fiber end cap
  • Plastic end cap
  • Oil-impregnated bearing
  • Leaf brush system
  • Carbon steel shaft
  • Diameter: 20.2mm
  • Length: 25mm
  • Height: 15.4mm
  • Shaft: could be made according to your demand
  • Voltage:
    • Operating voltage: 6.0-12.0V
    • Rated voltage: 12.0V
  • No load:
    • Speed: 30000rpm
    • Current: 0.32A
  • At max efficiency:
    • Speed: 24370rpm
    • Current: 1.39A
    • Torque: 3.9mNm
    • Output: 9.86W
    • Efficiency data: 60%
    • Stall torque: 20.6mNm
    • Stall current: 6.0A
    • Direction of rotation: CW/CCW
  • Note: all of the technical data could be custom made
  • Operating voltage: 6.0-12.0V
  • Rated voltage: 12.0V
  • Speed: 30000rpm
  • Current: 0.32A
  • Speed: 24370rpm
  • Current: 1.39A
  • Torque: 3.9mNm
  • Output: 9.86W
  • Efficiency data: 60%
  • Stall torque: 20.6mNm
  • Stall current: 6.0A
  • Direction of rotation: CW/CCW
  • Rear-view mirror
  • Headlamp adjuster
  • Mirror adjuster
  • RC model/toy
  • 2-pole stator
  • Sr ferrite permanent magnet
  • 3, 5, 7, 8, 9, 12 slots armature
  • Silicon-steel lamination with epoxy coating
  • High-carbon steel shaft
  • Cu-Ag alloys commutator
  • Copper-graphite brushes
  • Be-Cu leaf-brush commutating system
  • SECD round/flat shape housing
  • SECD end cap/PA66 + fiber end cap
