3.5V DC Micro Motor with (D x L) 32 x 22.8mm Housing/2mm Shaft, Ideal for Sprayer/Car DVD Player
  • 3.5V DC Micro Motor with (D x L) 32 x 22.8mm Housing/2mm Shaft, Ideal for Sprayer/Car DVD Player
  • 3.5V DC Micro Motor with (D x L) 32 x 22.8mm Housing/2mm Shaft, Ideal for Sprayer/Car DVD Player
3.5V DC Micro Motor with (D x L) 32 x 22.8mm Housing/2mm Shaft, Ideal for Sprayer/Car DVD Player
3.5V DC Micro Motor with (D x L) 32 x 22.8mm Housing/2mm Shaft, Ideal for Sprayer/Car DVD Player

3.5V DC Micro Motor with (D x L) 32 x 22.8mm Housing/2mm Shaft, Ideal for Sprayer/Car DVD Player

Get Latest Price
Payment Type:
T/T, L/C
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T, L/C
Product Description
Product Description
  • Specifications:
    • Motor housing (diameter x length): 32 x 22.8mm (material:SECD)
    • Shaft (diameter): 2.0mm carbon steel (nickel coating)
    • Way of commutation: metal brush
    • Structure: 2-pole stator and 3-slot armature
    • Rotation: CW/CCW, reversible
    • Rated voltage: 3.5V DC
    • At no load:
      • Speed: 3200 ±10% rpm
      • Current: 45mA (maximum)
    • At 10.0g.cm load:
      • Speed: 2700 ± 10%rpm
      • Current: 160mA(maximum)
    • At stall:
      • Current: 1000mA (maximum)
      • Torque: 70g.cm (minimum)
    • Options: shaft length, custom made technical data like voltage,speed and torque
    • Ideal for sprayer and car DVD player
  • Packing:
    • Quantity: 250 pieces
    • Gross weight: 11.0kg (approximate)
    • Measurement: 36.0 x 26.0 x 24.5cm
  • Motor housing (diameter x length): 32 x 22.8mm (material:SECD)
  • Shaft (diameter): 2.0mm carbon steel (nickel coating)
  • Way of commutation: metal brush
  • Structure: 2-pole stator and 3-slot armature
  • Rotation: CW/CCW, reversible
  • Rated voltage: 3.5V DC
  • At no load:
    • Speed: 3200 ±10% rpm
    • Current: 45mA (maximum)
  • At 10.0g.cm load:
    • Speed: 2700 ± 10%rpm
    • Current: 160mA(maximum)
  • At stall:
    • Current: 1000mA (maximum)
    • Torque: 70g.cm (minimum)
  • Options: shaft length, custom made technical data like voltage,speed and torque
  • Ideal for sprayer and car DVD player
  • Speed: 3200 ±10% rpm
  • Current: 45mA (maximum)
  • Speed: 2700 ± 10%rpm
  • Current: 160mA(maximum)
  • Current: 1000mA (maximum)
  • Torque: 70g.cm (minimum)
  • Quantity: 250 pieces
  • Gross weight: 11.0kg (approximate)
  • Measurement: 36.0 x 26.0 x 24.5cm
