DC Micro Motor for Vacuum Cleaner RS-380, Metal End Cap
  • DC Micro Motor for Vacuum Cleaner RS-380, Metal End Cap
DC Micro Motor for Vacuum Cleaner RS-380, Metal End Cap

DC Micro Motor for Vacuum Cleaner RS-380, Metal End Cap

Get Latest Price
Payment Type:
T/T or L/C
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T or L/C
Product Description
Product Description
  • Specifications:
    • Size (D x L): 27.7 x 37.8mm
    • Shaft diameter: 2.3mm
    • Metal end cap
    • Voltage: 4.8, 12, 24V
  • Measuring conditions:
    • Rated voltage: 24V DC
    • Motor position: to be measured with motor horizontallyheld
    • Environmental temperature: 25 ±10°C
    • Environmental humidity: 65 ±20% RH
  • Electrical characteristics (at initial stage after 30 secondsrun-in):
    • At no load:
      • Speed: 12,000 ±10%rpm
      • Current: 0.14A (maximum 0.27A)
    • At maximum efficiency:
      • Torque: 88.6g.cm
      • Speed: 9784 ±10% rpm
      • Current: 0.62A (1.1A maximum)
    • At stall:
      • Torque: 480g.cm
      • Current: 2.73A (4.9A maximum)
    • Direction of rotation: CW (clockwise when viewing from theoutput shaft end with positive voltage applied to positiveterminal)
  • Mechanical characteristics:
    • Dimensions drawing: as seen on picture
    • End play: 0.05 to 0.55mm
    • Operating temperature: -10 to 60°C
  • Ball bearing in output side
  • EMI suppression
  • Low-cogging design
  • High degree of protection
  • Small mechanical time constant
  • Resist intense vibrations
  • Zero axial gap
  • Low noise design
  • Fast response (small Tm)
  • High torque at low speed
  • PTC protection
  • Penolic resin base commutator
  • Epoxy coating armature
  • Lightweight and long lifespan
  • Size (D x L): 27.7 x 37.8mm
  • Shaft diameter: 2.3mm
  • Metal end cap
  • Voltage: 4.8, 12, 24V
  • Rated voltage: 24V DC
  • Motor position: to be measured with motor horizontallyheld
  • Environmental temperature: 25 ±10°C
  • Environmental humidity: 65 ±20% RH
  • At no load:
    • Speed: 12,000 ±10%rpm
    • Current: 0.14A (maximum 0.27A)
  • At maximum efficiency:
    • Torque: 88.6g.cm
    • Speed: 9784 ±10% rpm
    • Current: 0.62A (1.1A maximum)
  • At stall:
    • Torque: 480g.cm
    • Current: 2.73A (4.9A maximum)
  • Direction of rotation: CW (clockwise when viewing from theoutput shaft end with positive voltage applied to positiveterminal)
  • Speed: 12,000 ±10%rpm
  • Current: 0.14A (maximum 0.27A)
  • Torque: 88.6g.cm
  • Speed: 9784 ±10% rpm
  • Current: 0.62A (1.1A maximum)
  • Torque: 480g.cm
  • Current: 2.73A (4.9A maximum)
  • Dimensions drawing: as seen on picture
  • End play: 0.05 to 0.55mm
  • Operating temperature: -10 to 60°C
