NOVATEK78316 + Tuner MXL608 Mini DVB-T2 Receiver

NOVATEK78316 + Tuner MXL608 Mini DVB-T2 Receiver

Get Latest Price

Payment Type:: T/T, L/C

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C

Product Description

Features:

Fully SD/HD DVB-T/T2, SD/HD MPEG2 and MPEG4 AVC H.264
Full HD, support up to 1080P
Auto and manually scan all available TV and radio channels
Aspect ratio 16:9 and 4:3
HDMI, YUV, RCA, coaxial output
Multilingual subtitle output supported
Powerful and highly effective 7-day EPG function
Parental lock
PVR, time shift via USB2.0
Multimedia playback and software upgrade via USB2.0
Stores up to 1,000 programs

Tuner

RF input frequency: 44-1002MHz
Bandwidth: 6/7/8MHz
Input level: -83dBm
Signal input: IEC-type female
Chipset: MSTAR 7816
Mpeg transport stream and A/V decoding
Video standard: MPEG-4 AVC/H.264 HP at L4
SCART video model CVBS/RGB (for Europe)
Aspect ratio: 4:3, 16:9
Video resolution: 576i, 576p, 720p and 1080i, 1080P
Audio standards: ISO/IEC 14.496-3, AAC, AAC+
Audio mode: mono, dual-channel, stereo

Multimedia formats:

Picture: JPEG, BMP, PNG
Audio: MP3,WMA
Video: MKV, AVI, DIVX, XVID, MOV, VOB, FLV, 3GP, DAT, MPEG, MPG, MP4, TS, TRP

Input voltage: 5V adapter

Real standby: <1W

Power consumption: 8W (max)

USB: for firmware upgrade, PVR, multimedia playback

Demodulation: QPSK, 16QAM, 64QAM, 256QAM

Code rate: 1/2, 3/5,2/3, 3/4, 4/5, 5/6

Guard: from 1/128 to 1/4

FFT mode: from 1 to 32K

Standard

DVB-T (ETSI EN 300 744)
DVB-T2 (ETSI EN 302 755)

Rear panel output

HDMI 576i, 576p, 720p and 1080i, 1080P

Loop through output: IEC-type, connector, single tuner

Coaxial: RCAX1

YpbPr RCAX3

L/R audio RCAX2

CVBS

SCART (optional)

Fully SD/HD DVB-T/T2, SD/HD MPEG2 and MPEG4 AVC H.264

Full HD, support up to 1080P

Auto and manually scan all available TV and radio channels

Aspect ratio 16:9 and 4:3

HDMI, YUV, RCA, coaxial output

Multilingual subtitle output supported

Powerful and highly effective 7-day EPG function

Parental lock

PVR, time shift via USB2.0

Multimedia playback and software upgrade via USB2.0

Stores up to 1,000 programs

RF input frequency: 44-1002MHz

Bandwidth: 6/7/8MHz

Input level: -83dBm

Signal input: IEC-type female

Chipset: MSTAR 7816

Mpeg transport stream and A/V decoding

Video standard: MPEG-4 AVC/H.264 HP at L4

SCART video model CVBS/RGB (for Europe)

Aspect ratio: 4:3, 16:9

Video resolution: 576i, 576p, 720p and 1080i, 1080P

Audio standards: ISO/IEC 14.496-3, AAC, AAC+

Audio mode: mono, dual-channel, stereo

Picture: JPEG, BMP, PNG

Audio: MP3,WMA

Video: MKV, AVI, DIVX, XVID, MOV, VOB, FLV, 3GP, DAT, MPEG, MPG, MP4, TS, TRP

DVB-T (ETSI EN 300 744)

DVB-T2 (ETSI EN 302 755)
