600TVL Dome High-definition IR Camera Series, 0 to 40m IR Distance

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Specifications:

Color high-sensitivity CCD image sensor, it shows the superior image effects
High-resolution, BLC, AGC, AWB, mirror function
The housing is made by special material, waterproof up to IP 65 level
The fourth generation of IR array illuminant, which can improve the photoelectric conversion efficiency
The IR LED lifetime more than five years and night vision has an effective result
Use accurate constant current source technology, the LED board is designed to separate
from the control circuit board, to make it more stability
High-power lighting protection circuit, to make the CCD board more stability
Image sensor: 1/3 color Sony CCD
CCD total pixels:
- P (H x V): 648 x 488
- N (H x V): 648 x 488
Scanning system: PAL/NTSC
Sync system: internal
Minimum illumination: 1 Lux F1.2/0 Lux (IR on)
Resolution: 600TVL
Lens: MTV3.6 to 16mm (optionally)
IR distance: 0 to 40m
IR LED: 1 piece
WBC: 1/50 to 1/100,000 auto
AG: AGC
S/N ratio: ≥48dB
Exposure time: auto
Auto iris: electronic shutter
Mirror function: on/off (optionally)
BLC: on/off (optionally)
Video output: 1.0Vp-p/75Ω
Gamma correction: 0.45
Working temperature: -20 to -50℃
Working humidity: 85% RH
Power supply: 12V DC
Power consumption: ≤450mA
Measurement: 75 x 94mm

Color high-sensitivity CCD image sensor, it shows the superior image effects

High-resolution, BLC, AGC, AWB, mirror function

The housing is made by special material, waterproof up to IP 65 level

The fourth generation of IR array illuminant, which can improve the photoelectric conversion efficiency

The IR LED lifetime more than five years and night vision has an effective result

Use accurate constant current source technology, the LED board is designed to separate

from the control circuit board, to make it more stability

High-power lighting protection circuit, to make the CCD board more stability

Image sensor: 1/3 color Sony CCD

CCD total pixels:

Scanning system: PAL/NTSC

Sync system: internal

Minimum illumination: 1 Lux F1.2/0 Lux (IR on)

Resolution: 600TVL

Lens: MTV3.6 to 16mm (optionally)

IR distance: 0 to 40m

IR LED: 1 piece

WBC: 1/50 to 1/100,000 auto

AG: AGC

S/N ratio: ≥48dB

Exposure time: auto

Auto iris: electronic shutter

Mirror function: on/off (optionally)

BLC: on/off (optionally)

Video output: 1.0Vp-p/75Ω

Gamma correction: 0.45

Working temperature: -20 to -50℃

Working humidity: 85% RH

Power supply: 12V DC

Power consumption: ≤450mA

Measurement: 75 x 94mm

P (H x V): 648 x 488

N (H x V): 648 x 488
