ATSC receivers, USB media playback, HDMI for Mexico, North America, Korea

ATSC receivers, USB media playback, HDMI for Mexico, North America, Korea

Get Latest Price

Payment Type:: Telegraphic Transfer (TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

Main features:

Fully ATSC compliant, supports full HD 1,080P
Supports SD/HD MPEG2 and MPEG4 AVC H.264
Auto and manually scans all available TV and radio channels
HDMI, scart/RCA, coaxial output, L/R audio
Multiple languages subtitle output supported
Powerful and highly effective 7-day EPG function
PVR, time shift, software upgrade via USB2.0
Aspect ratios: 16:9 and 4:3
USB media playback
Four digits LED display
Supports Teletext
Parental lock

Tuner details:

IF input frequency range: 56 - 866MHz
Bandwidth: 6MHz
Input level: -83dBm
Signal input: IEC type female

Channel decoding:

Standard: ATSC
Demodulation: 8VSB
FEC: 1/2, 2/3, 3/4, 5/6, 7/8, automatic
Modes: 2K, 8K
Guard: 1/4,1/8,1/16,1/32

Demultiplexer:

Standard IEC 13818-1, ARIB STB-B10
Input maximum bit stream rate: 120Mbps (serial)/15Mbps (parallel)
Rear panel output
HDMI 576i, 576P, 720P and 1,080i, 1,080P
Loop through output: IEC type, connector, single tuner, HDMI

Video decoding:

Standard: MPEG-4 AVC/H.264 HP at L4
HDMI, Coaxial, CVBS, L/R audio, YUV
Aspect ratio: 16:9, 4:3
Video resolutions: 576i, 576P, 720P and 1,080i, 1,080P

Audio decoding:

Standard: IEC 14.496-3
Audio mode: mono, dual-channel, stereo, Dolby AC3/E-AC3
Size of the machine: 168 x 115 x 36mm

Accessories:

Remote control
User's manual
RCA cable
Adapter (12V/1.5A)

Loading:

20ft GP: 6,500pcs
40ft GP: 13,000pcs
40ft HQ: 15,500pcs

Fully ATSC compliant, supports full HD 1,080P

Supports SD/HD MPEG2 and MPEG4 AVC H.264

Auto and manually scans all available TV and radio channels

HDMI, scart/RCA, coaxial output, L/R audio

Multiple languages subtitle output supported

Powerful and highly effective 7-day EPG function

PVR, time shift, software upgrade via USB2.0

Aspect ratios: 16:9 and 4:3

USB media playback

Four digits LED display

Supports Teletext

Parental lock

IF input frequency range: 56 - 866MHz

Bandwidth: 6MHz

Input level: -83dBm

Signal input: IEC type female

Standard: ATSC

Demodulation: 8VSB

FEC: 1/2, 2/3, 3/4, 5/6, 7/8, automatic

Modes: 2K, 8K

Guard: 1/4,1/8,1/16,1/32

Standard IEC 13818-1, ARIB STB-B10

Input maximum bit stream rate: 120Mbps (serial)/15Mbps (parallel)

Rear panel output

HDMI 576i, 576P, 720P and 1,080i, 1,080P

Loop through output: IEC type, connector, single tuner, HDMI

Standard: MPEG-4 AVC/H.264 HP at L4

HDMI, Coaxial, CVBS, L/R audio, YUV

Aspect ratio: 16:9, 4:3

Video resolutions: 576i, 576P, 720P and 1,080i, 1,080P

Standard: IEC 14.496-3

Audio mode: mono, dual-channel, stereo, Dolby AC3/E-AC3

Size of the machine: 168 x 115 x 36mm

Remote control

User's manual

RCA cable

Adapter (12V/1.5A)

20ft GP: 6,500pcs

40ft GP: 13,000pcs

40ft HQ: 15,500pcs
