1) Pure sine wave
2)Big charger (35/70A )
3) P.F.C. (power factor correction)
4)10ms transfer time
Features
1) Pure sine wave
2)Big charger (35/70A )
3) P.F.C. (power factor correction)
4) Includes remote control with 10 metre cable
5) Less than 10ms transfer time for computer use
6)very Stable to standwith all kinds of inductive, capacitive loads ect.
|
MODEL |
GF Inverter 2012 |
GF Inverter 3012 |
GF Inverter 2024 |
GF Inverter 3024 |
|
|
CAPACITY |
2000 VA/ 2000 W |
3000 VA/ 3000 W |
2000 VA/ 2000 W |
3000 VA/ 3000 W |
|
|
INPUT |
|||||
|
Voltage |
Nominal Voltage |
230 VAC |
|||
|
Acceptable Voltage Range |
184 - 253 VAC (±4%) |
||||
|
FrequencyRange |
50 Hz (auto sensing) |
||||
|
OUTPUT |
|||||
|
AC Voltage Regulation (Batt. Mode) |
230 VAC±10% |
||||
|
FrequencyRange(Batt. Mode) |
50 Hz ±1 Hz |
||||
|
Transfer Time |
10 ms typical |
||||
|
Waveform (Batt. Mode) |
Pure Sine Wave |
||||
|
BATTERY |
|||||
|
BatteryVoltage |
12 VDC |
24 VDC |
|||
|
Floating Charge Voltage |
13.4 VDC ± 2% |
26.8 VDC ± 2% |
|||
|
Low Battery Alarm Voltage |
10.8 VDC ± 2% |
21.6 VDC ± 2% |
|||
|
Shutdown Voltage |
10.0 VDC ± 2% |
20.0 VDC ± 2% |
|||
|
Overcharge Protection |
15.0 VDC ± 2% |
30.0 VDC ± 2% |
|||
|
Maximum Charge Current |
70 A |
70 A |
35 A |
35 A |
|
|
PROTECTION |
|||||
|
Full Protection |
Overload and short circuit breaker |
||||
|
COMMUNICATION & OTHER |
|||||
|
Communication |
RJ11(Used for factory testing.No customer interface available) |
||||
|
Safety Certiffcation |
Compliance with Ul458 CE(EN60950) |
||||
|
EMI Classification |
FCC, CLASS A EN50091-2, CLASS A |
||||
|
Audible Noise |
60dB max |
||||
|
ALARM |
|||||
|
Low Baery |
beep 0.5s every 5 s |
||||
|
Overload |
beep 0.5s every 5 s |
||||
|
Over Temperature |
beep 0.5s every 5 s |
||||
|
Fault |
beep continuous |
||||
|
PHYSICAL |
|||||
|
Dimension, D X W X H (mm) |
442 X 218 X 179 |
||||
|
Net Weight (kgs) |
2000 VA 20 kgs |
3000 VA 22 kgs |
|||
|
OPERATING ENVIRONMENT |
|||||
|
Humidity |
0 to 90% Relative Humidity(Non-condensing) |
||||
|
Operating Temperature |
0°Cto 40°C |
||||
|
Storage Temperature |
-15°Cto 50°C |
||||
