Basic Info

Product Description

Basic Info.

Model NO.

MV2025TWSP

Trademark

ALLTECH

Origin

China

Production Capacity

5000 Units/Year

Product Description

Functions & Features:
n AES encrypted video transmission
n aluminum alloy casing with good shock resistance
n external digital frequency controller; lithium battery replaceable
n mobile video transmission in NLOS (No line of sight) condition
n COFDM modulation and H.264 compression for stable and high-quality audio and video signal
n HDMI and HD-SDI signal input
n Multiple bandwidth adjustable, 1.5/2/4/6/7/8MHz
n Video input PAL/NTSC optional (PAL as default)
n Full HD transmission, clear image with resolution 1080i/P
n Portable HD repeater compatible to increase the transmission distance
n Perfect compatibility with satellite system or HD video conference system
n RF power adjustable; RF bandwidth adjustable
n Multiple receiver systems optional for diversity of applications

Power supply	Working voltage V	DC7V-16.8V
Power supply	Working current A	≤0.6A@DC12.5V
RF	Working frequency range	328-352MHz/560-760MHz/1.2-1.5GHz/2-2.5GHz	Customized
	Channel center frequency	338MHz/595MHz/1.2GHz/2.4GHz	Customized
	Center frequency shift	±20Hz
	RF bandwidth MHz	1.5/2MHz,4MHz,6/7/8MHz
	Power output dBm	≥22dBm/IL=1
	Power output adjustable range	15dB
	C/N	≥28dB @ 22dBm
	stray emission	≤-36dBm (beyond range of carrier center frequency fc±5MHz)
	Modulation	COFDM
	Constellation	QPSK, 16QAM and 64QAM optional
	FEC	1/2, 2/3, 3/4, 5/6, 7/8 optional
	Guard interval	1/4, 1/8, 1/16, 1/32 optional
CVBS	Video encoding	H.264
	Video input level	1~1.2Vp-p@75Ω
	Video input mode	PAL/NTSC
	Video white-bar level mV	650~720mV
	Video synchronous level mV	260~275mV
	Audio input	Left/right channel, stereo
HDMI	Standard supported	576i50, 480i60, 720p50, 720p60, 1080i50, 1080i60, 1080p25, 1080p30
HDMI	HDCP protocol	Support
SDI	Standard supported	576i50, 480i60, 720p50, 720p60, 1080i50, 1080i60, 1080p25, 1080p30
SDI	Input level mV	800±80
Interface	RS232 control	Standard RS232 level
Interface	RS232 data	Standard RS232 level, support 1200~115200 bps
