Mobile Video Transmitter of Broadcasting Camera Mounted

Mobile Video Transmitter of Broadcasting Camera Mounted

Get Latest Price

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Basic Info.

Model NO.

MV2025TKME

Origin

Shenzhen, China

Production Capacity

5000 Units/Year

Product Description

Functions & Features:
- Super low latency
- ABS encryption
- Portable and practical with simple operation
- Working frequency directly display on panel
- Working frequency adjustable within specified range
- Builtin high-performance power amplifier
- COFDM modulation and MPEG-2 video compression for stable and high-quality transmission
- A/V signal simultaneously input, one-channel video input
- Left/right channel audio and unbalanced stereo input
- 1.25/2.5/6/7/8MHz multiple bandwidth output
- Video input PAL/NTSC optional (default as PAL)
Mobile Video Transmitter of Broadcasting Camera Mounted

Power Supply
Working voltage V			DC12V~DC16V
Working current A			≤2.5A@DC12.5V
Battery lasting			2.5 hours
Video Transmission
Frequency output range	300MHz~450MHz,560~760MHz or user customized
RF bandwidth	6/7/8MHz or 1.25/2.5MHz
Power output	18~33dBm adjustable with 1dB step
C/N	30dB @ 30dBm
SHG	>52dBc
Encryption	AES/ALLTECH Basic Scrambling
Modulation			COFDM
Constellation			QPSK,16QAM,64QAM optional QPSK/16QAM/64QAM @ 6/7/8MHz
FEC			1/2,2/3,3/4,5/6,7/8 optional
Carrier			2K
Video encoding				MPEG-2/MPEG-4
Video input level			1Vp-p@75Ω,PAL
Video resplution					720×576(PAL) 720×480(NTSC)
Power flatness			Full band ≤2dB, 8MHz (within)≤0.5dB
A/V interface		BNC/RCA
Video bitrate			15Mbps(MAX)
RS232 control interface			Standard RS232 level, 9600, 8, N, 1
RS232 data interface			Standard RS232 level, support 1200~115200
CBER			<2.0E-4
Environment
Working temperature	-25°C~55°C
Storage temperature	-40°C~70°C
Appearance
Dimension			193.6mm×116mm×66.8mm
Weight			1.27kg
