Basic Info

Product Description

Basic Info.

Model NO.

MV2025TWLE

Production Capacity

10, 000 PCS/Year.

Product Description

Functions& Features:
1. Super low latency
2. Working frequency and RF bandwidth self-adapted within specified range
3. Low power consumption transmission
4. Disconnectable lithium battery, easy operation and battery replacement

Specfication:
Lithium battery: DC10.8V/ 1800mAh
Lithium battery charger: (dedicated) 12.6V/2A
Fraquency output range: 300~450MHz; 560~760MHz or user customized
RF bandwidth: 6/7/8MHz or 1.25/2.5MHz
Power output: 500mW
Modulation: COFDM
Video encoding: MPEG-2/MPEG-4
Encryption: AES/ALLTECH Basic scrambling
Constellation: QPSK/16QAM@1.25/2.5 MHz; QPSK/16QAM/64QAM
Carrier: 2K
Video input level: 1~1.2Vp-p@75Ω
Video input format: PAL/NTSC
200-500MW Mini-Type Wireless Video Transmitter China OEM

Power Supply
Lithium battery	DC10.8V /1800mAh
Lithium battery charger	12.6V/1A
Video Transmission
Frequency output range	300MHz~1.2GHz or user customized
RF bandwidth	2/3/4/6/7/8MHz
Power output	500mW
CNR	≥28dB@27dBm
SHG	>52dBc
Modulation	COFDM
Constellation	QPSK/16QAM/64QAM optional
FEC	1/2, 2/3, 3/4, 5/6, 7/8 optional
GUI	1/4, 1/8, 1/16, 1/32 optional
Encryption	AES/Alltech Basic Scrambling
Encoding	H.264
Video input level	1~1.2Vp-p@75Ω
Video input format	PAL/NTSC
Video amplitude-frequency characteristic	0~4.8MHz	-0.5~1.5dB
	5.5MHz	-4.0~1.5dB
Audio input	Left/right channel, stereo
RS232 control interface	Standard RS232 level, 9600, 8, N, 1
RS232 data interface	Standard RS232 level, support 1200~115200
Transmission delay	Less than 1s
Environment
Working temperature	-25~55°C
Environment humidity	No less than 95%
Protect standard	Anti-corrosion and shakeproof
Storage temperature	-40~70°C
Appearance
Dimension	112.2X85X27.3mm
Weight	Transmitter:0.27Kg; battery: 0.22 Kg
RF interface	SMA
