Cofdm Body-Worn 2W Video Transmitter

Get Latest Price

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Basic Info.

Model NO.

MV2025TBHE

Oscillator Circuit

LC or Crystal Oscillator

Transport Package

Cartons

Specification

CE, ISO9001, SGS

Trademark

ALLTECH

Origin

Shenzhen, China.

Production Capacity

5000/Year

Product Description

Functions & Features:

1. Default power output: 2W and maximum 4W (with existed size)

2. Super low latency (20-60ms end to end)

3. ABS/AES encryption with encryption level optional

4. Working frequency customized within range 300MHz to 2.4GHz

5. Video input PAL/NTSC optional (default as PAL)

6. Audio and video signal simultaneously input, one-channel video input

7. Left/right channel audio and unbalanced stereo input

8. Fully-enclosed waterproof case, dustproof and good impact resistance

9. Distance no less than 13km in LOS and 2-5km in NLOS

Power Supply
Working voltage V	DC12V~DC16V
Working current A	≤2.7A@DC12.5V
Video Transmission
Frequency output range	300MHz~450MHz,560~760MHz or user customized
RF bandwidth MHz	1.25/2.5MHz or 6/7/8MHz
Power output	21~36dBm power output adjustable with 1dB step
C/N	≥28dB@32dBm
SHG	>52dBc
Encryption	AES/ALLTECH Basic scrambling
Modulation	COFDM
Constellation	QPSK/16QAM @ 1.25/2.5MHz QPSK/16QAM/64QAM @ 6/7/8MHz
FEC	1/3, 2/3@ 1.25/2.5MHz 1/2, 2/3, 3/4, 5/6, 7/8 @ 6/7/8MHz
Carrier	2K
GUI	1/4, 1/8, 1/16, 1/32 optional
Video encoding	MPEG-2/MPEG-4
Video input level	1~1.2Vp-p@75Ω
Video input format	PAL/NTSC
Video resolution	720x576(PAL) 720x480(NTSC)
Video white bar amplitude mV	650~720mV
Video synchronous amplitude mV	260~275mV
Video amplitude-frequency characteristic dB	0~4.8MHz	-0.5~1.5
	5.5MHz	-4.0~1.5
Audio input	Left/right channel, stereo
RS232 control interface	Standard RS232 level, 9600, 8, N, 1
RS232 data interface	Standard RS232 level, support 1200~115200
Delay	60ms
Environment
Protect standard	IP66, dustproof and rainproof
Working temperature	-25°C~55°C
Storage temperature	-40°C~70°C
Appearance
Dimension	238mm×140mm×75mm
Weight	2.5Kg
