Cofdm Wireless Portable Multifunctional Receiver for Drone

Cofdm Wireless Portable Multifunctional Receiver for Drone

Get Latest Price

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Basic Info.

Model NO.

MV2025RH7

Weight

10.1kg

Color

Black

MOQ

Customization

Yes

OEM

Yes

Transport Package

Carton

Specification

SGS

Trademark

ALLTECH

Origin

Shenzhen, China

Production Capacity

5000pieces/Year

Product Description

Functions & Features:
MPEG-2/MP@ML/4:2:0 DVD decoding standard
Receiver internal parameters configurable
Auto front error correction
Frequency continuously adjustable
Power off memory
Standard definition image and Hi-Fi stereo output
Feed short-circuit protect and indication
Lithium battery power supply with power display
AVI format video recoding;USB flash disk video recording
H.264 video compression with Ethernet transmission
Full-featured PTZ camera remote control
COFDM demodulation and high receiving sensivitity (single antenna -92dBm, diversity receiving -96dBm)

Power Supply
Working voltage V		AC220V±20V, DC14V~DC16V
Working current A		≤2.5A@ DC15.5V
Video Receiving
Frequency input range		170MHz~860MHz
RF bandwidth		1.25/2.5MHz or 6/7/8MHz
Receiving sensitivity		-96dBm~-20dBm@8M/-106dBm~-20dBm@1.25M
Demodulation		COFDM
Video decoding standard	MPEG-2/MPEG-4
Constellation		QPSK/16QAM @ 1.25/2.5MHz; QPSK/16QAM/64QAM @ 6/7/8MHz
FEC		1/3,2/3 @ 1.25/2.5MHz,1/2, 2/3, 3/4, 5/6, 7/8 @ 6/7/8MHz
Carrier		2K
GUI		1/8, 1/16 @ 1.25/2.5MHz; 1/4, 1/8, 1/16, 1/32 @ 6/7/8MHz
Video output level		1~1.2Vp-p@75Ω
Video output format		PAL/NTSC
Video white bar amplitude mV		650~720mV
Video synchronous amplitude mV		260~275mV
Video amplitude-frequency characteristic dB		0~4.8MHz	-0.5~1.5
		5.5MHz	-4.0~1.5
Rx feed output voltage		DC10V~DC12V
Rx feed output current (MAX)		800mA
Audio output		Left/right channel, stereo
RS232 control interface		Standard RS232 level, 9600, 8, N, 1
RS232 data interface		Standard RS232 level, support 1200~115200
Command
Command air baudrate		600bps~19200bps
Power output		≥32dBm
Keyboard communication protocol		Pelco-P such multiple protocols with baudrate adjustable
Keypress		Rubber button, numeric keypad, camera function keys
Environment
Working temperature		-25°C~55°C
Storage temperature		-40°C~70°C
Appearance
Dimension		460mm×370mm×180mm
Weight		10.1kg
Battery weight		1.1kg
Color		Black
