Cofdm HD 3G Wireless Digital Portable Suitcase Video Receiver

Cofdm HD 3G Wireless Digital Portable Suitcase Video Receiver

Get Latest Price

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Basic Info.

Model NO.

MV2025RH8-AJK/1080i(3G)

MOQ

Customization

Yes

OEM

Yes

Transport Package

Carton

Specification

CE, ISO9001, SGS

Trademark

ALLTECH

Origin

Shenzhen, China

Production Capacity

10, 000 PCS/Year.

Product Description

Functions & Features:
1.Full HD H.264/MPEG-2 decoding with D1, 720P, 720i, 1080i, 1080P such HD formats
2.Channels parameters panel configurable
3. H.264 video compression with Ethernet transmission
4. High definition image and hi-fi stereo output
5. COFDM demodulation and high receiving sensitivity
6. Video receicing bandwidth adjustable with broadcasting level standard
7. Full UI interface control
8. Dual track audio and CVBS/YUV/HDMI output
9. 1.5/2/4/6/7/8MHz bandwidth adjustable
10. Multiple channels storage and management; one-key selection for channels switching
11. SATA/SD card/USB flash disk video recording
12. SATA/SD card/USB flash disk files browsing, A/V files play and files/folders deletion in media
13. ABS/AES decryption
14. Two-channel data output and unidirectional RS232 data transmission (user data and GPS data)
15. 3G network video transmission optional
16. One keyboard controls upto 256 cameras
17. Prefences user editable (preset, cruise, groups, etc)

Power Supply
Working voltage V			AC220V±20V; DC12V~16V
Working current A			≤3.5A@DC12.5V (if audio transmission is off) ≤7.5A@ DC12.5V (if audio transmission is on)
Video Receiving
Frequency input range			170MHz~860MHz
RF bandwidth			1.5/2/4/6/7/8MHz
Receiving sensitivity			-96dBm~-20dBm@8M, -106dBm~-20dBm@2M
Demodulation			COFDM
Decryption			AES/ALLTECH Basic Scrambling
Video output format			PAL/NTSC
Video decoding standard			H.264/MPEG2 compatible and self-adapted
Audio decoding standard			ISO/IEC11172-3 MPEG-1, ISO/IEC13818-3 MPEG-2 (Layer I&II)
Video output interface			CVBS×2,HDMI/DVI×1, YUV×1, SDI×1 (customize), ASI×1 (customize)
Video resolution (MAX)			1920×1080×60i/50i
CVBS video output			Video output level		1~1.2Vp-p@75Ω
			Video white bar amplitude mV		650~720mV
			Video synchronous amplitude mV		260~275mV
Analog video amplitude-frequency characteristic dB			0~4.8MHz		-0.5~1.5
			5.5MHz		-4.0~1.5
Analog audio output			Left/right channel, stereo
HD-SDI video output			Standard	SMPTE 425M (Level A and Level B), SMPTE 424M, SMPTE 292, SMPTE 259M-C SMPTE 272M SMPTE 299M
			Input amplitude mV	800±80
HDMI video output			Version	HDMI 1.3
			HDCP protocol	Support
YUV/YPcPr/YCbCr			YPbPr@720P, YCbCr@1080i
RS232 control interface			Standard RS232 level, 9600, 8, N, 1
RS232 data interface			Standard RS232 level, support 1200~115200
Command
Command air baudrate		600bps~19200bps
Power output		≥32dBm
Keyboard communication protocol		Pelco-P such multiple protocols with baudrate adjustable
Keypress		Rubber button, numeric keypad, camera function keys
Video Recording
Video format		PAL
Video resolution		2CIF/4CIF, HD1080i(1920×1080),HD720P(1280×720)
Image brightness adjustable range		1~255 default 128
Image contrast adjustable range		1~127 default 64
Image saturability adjustable range		1~127 default 64
Audio sample frequency		8KHz
Audio data format		ADPCM, G.711 A/U, G.726, AMR, AAC
Audio gain adjustable range		0~100
USB interface		USB2.0, mountable USB flash disk with HD1080i/P HD bitsream direct recording
Video recording media		SD card, USB flash disk, mobile HDD with HD1080i/P HD bitstream direct recording
Network interface		10/100Base-T self-adapted Ethernet, RJ45 with HD1080i IP output
Audio Transmission
Audio Tx frequency		470.5~479.950MHz; factory setting:479.950MHz
Audio Tx power output		≥40dBm
Audio Tx modulation		GFSK
SHG		>62dBc
Frequency interval		150KHz
Audio decoding overall bitrate		4800bps
Audio sample		8KHz 16bit
Audio Tx delay		1~60s
Audio input signal strength (MAX)		320mVpp
3G Video Transmission
Video encoding		H.264
Video frame rate		3G one card transmission average: 15~20Fps
Video format		CIF: 352×288
Snapshot		D1:704×576 pixels, CIF: 352×288 pixels, QCIF: 176×144 pixels optional
Audio		Single track
Audio encoding		G723.1 compression (8K sampling)
Environment
Working temperature	-25°C~55°C
Storage temperature	-40°C~70°C
Appearance
Dimension	600mm×391mm×230mm
Weight	10kg
Battery weight	1.1kg
Color	Black
