Digital Wireless Video Cofdm Receiver with Diversity Receiving Technology

Digital Wireless Video Cofdm Receiver with Diversity Receiving Technology

Get Latest Price

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Basic Info.

Model NO.

MV2025/1080

Customization

Yes

OEM

Yes

MOQ

Transport Package

Paper Carton

Specification

5kg

Trademark

ALLTECH

Origin

Shenzhen, China

Production Capacity

10, 000 PCS/Year.

Product Description

Functions & Features:

Full HD H.264/MPEG-2 decoding with D1, 720P, 720i, 1080i, 1080P such HD encoding formats
H.264 video compression with Ethernet transmission
High definition image and hi-fi stereo output
Video receiving bandwidth adjustable with broadcasting level receiving indexes
Full UI interface control
Dual track audio output, CVBS/YUV/HDMI output
1.5/2/4/6/7/8MHz bandwidth adjustable
Multiple channel storage and management, one-key selection for decoding display
SATA/SD card/USB flash disk video recording
SATA/SD card/USB flash disk files browsing, A/V files play and file/folder deletion in media
Product firmware and kernel updating
ABS/AES decryption

Power Supply
Working voltage V	AC220V±20V
Working current A	≤1.5A@DC12.5V (if audio transmission is off) ≤5.5A@DC12.5V (if audio transmission is on)
Video Receiving
Frequency input range		170MHz~~860MHz
RF bandwidth		1.5/2/4/6/7/8MHz
Receiving sensitivity		-96dBm~-20dBm@8M, -106dBm~-20dBm@2M
Demodulation		COFDM
Decryption		AES/ALLTECH Basic Scrambling
Video output format		PAL/NTSC
Video decoding standard		H.264/MPEG2, double decoding self-adapted
Audio decoding standard		ISO/IEC11172-3 MPEG-1, ISO/IEC13818-3 MPEG-2 (Layer I&II)
Video output interface		CVBS×2, HDMI/DVI×1, YUV×1,SDI×1 (customize), ASI×1 (customize)
Video resolution		1920×1080×60i/50i
CVBS SD video output		Video output level			1~1.2Vp-p@75Ω
		Video white bar amplitude mV			650~720mV
		Video synchronous amplitude mV			260~275mV
Analog video amplitude-frequency characteristic dB		0~4.8MHz			-0.5~1.5
		5.5MHz			-4.0~1.5
Analog audio output		Left/right channel, stereo
HD-SDI video output		Standard		SMPTE 425M (Level A and Level B), SMPTE 424M, SMPTE 292, SMPTE 259M-C SMPTE 272M SMPTE 299M
		Input amplitude mV		800±80
HDMI video output		Version		HDMI 1.3
		HDCP protocol		Support
YUV/YPbPr/YCbCr output		YPbPr@720P,YCbCr@1080i
RS232 control interface		Standard RS232 level, 9600, 8, N, 1
RS232 data interface		Standard RS232 level, support 1200~115200
Display Part
TFT LCD			1.8"
			262K true color
			128×160 pixels
Audio Transmission
Audio Tx frequency			470.5~479.950MHz, factory setting: 479.950MHz
Audio Tx power output			≥40dBm
Audio Tx modulation			GFSK
SHG			>62dBc
Frequency interval			150KHz
Audio encoding overall bitrate			4800bps
Audio sample			8KHz 16bit
Audio Tx delay			1~60 S
MIC input signal strength (MAX)			320mVpp
Conference microphone input signal strength (MAX)			Common conference microphone: 1.5Vpp; high-amplitude conference microphone: 15Vpp
Environment
Working temperature			-25~55
Storage temperature			-40~70
Appearance
Dimension			482mm×360mm×44mm
Weight			5.5kg
