Cofdm Wireless HD Portable Video Repeater

Cofdm Wireless HD Portable Video Repeater

Get Latest Price

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Basic Info.

Model NO.

MV2025SS2F8-B

Color

Green

MOQ

Factory

Yes

OEM

Yes

Transport Package

Carton

Specification

ISO9001, SGS

Trademark

ALLTECH

Origin

Shenzhen, China

Production Capacity

5000pieces/Year

Product Description

Functions & Features:
n   Full HD H.264/MPEG-2 decoding with D1, 720P, 720I, 1080I, 1080P such HD formats
n   Working as separate transmitter and receiver
n   ABS encryption
n   One-channel video and two-channel audio (left/right channel) signals simultaneously input
n   1.5/2/4/6/7/8MHz bandwidth optional
n   Outdoor rainproof case design
n   Working frequency and other parameters panel display
Cofdm Wireless HD Portable Video Repeater

Power Supply
Working voltage V	DC12V~DC16V
Working current A	≤3.5A@DC12.5V
Continuous lasting	>4 hours
Receiving Part
Rx input frequency range	170MHz~860MHz
Rx RF bandwidth	1.5/2/4/6/7/8MHz
Rx frequency range	170MHz~860MHz or user customized
Rx sensitivity	-106dBm@2M/-96dBm@8M
Rx factory default frequency	300MHz~450MHz
Rx feed output voltage	DC12V±0.5V
Rx feed output current (MAX)	800mA
Transmission Part
Tx frequency output range	550MHz~810MHz
Tx RF bandwidth	8MHz
Tx frequency range	560MHz~760MHz or user customized
Tx factory default frequency	560MHz~760MHz
Tx power output	32dBm~34dBm
Tx output frequency spectrum CNR	≤-28dB@32dBm
Tx second harmonic components	>52dBc
Environment
Working temperature	-25°C~55°C
Storage temperature	-40°C~70°C
Appearance
Dimension	354mm×283mm×151mm
Weight	12.4kg
