Vehicle Speed Governor Car Speed Limiter Vehicle Speed Controller Digital Type
- Payment Type:
- L/C, T/T, Paypal, Western Union
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Shenzhen |
|---|---|
| Payment Type: | L/C, T/T, Paypal, Western Union |
Product Description
Product Description
Feature
1. Limit speed intelligently according to speed limit values of the road
2. The device is widely applicable, can be used in mostly 12 v ~ 24 v vehicles
3. It is easy to install the device and it is anti-shock
4. Strong stability: Design of short circuit protection, built-in circuit of preventing over current.
5. Design of combining electronic technology with machinery, one installing for forever.
6. Study intelligently the features of vehicle. It will reduce setting of same kind of vehicle.
7. Alarm of cutting of power wire.
8. Limit speed safely without affecting vehicle's horsepower
Function
1. Feet management
(1)Record the data of running status:
Speed and status of vehicle's running status.
(2) Record the historical route of vehicle.
2. Over speeding alarm and limit vehicle speed
When vehicle speed become over the speed limit value, the device sound the alarm and send the alarming data to the control center. If the driver didn't slow down the car, the device will limit vehicle speed.
3. Function of self-inspection
When the device connects the power, it inspects itself and sound "di" shows that it works well.
4. Function of power-off protection
The device has built-in storage and will update the important data to the control center.
5. Function of anti-interference
The device takes measures to be resistant to interference, so it can ensure the reliability of recorded data.
Main specification
Function of self-inspection
When the device connects the power, it inspects itself and sound "di" shows that it works well.
Speed limit mode
The device's default mode is Mode 1
Function of Speed Limit
When vehicle speed reach the speed limit value, the device sound the alarm ("di", "di", "di" ring slowly)
When vehicle speed is more 10% than the speed limit value, the device will limit vehicle speed to make it less than the speed limit value ("di", "di", "di" ring fast)
When vehicle change lanes, the device will stop limiting vehicle speed and sound the alarm ("di", "di", "di" ring fast)
When vehicle speed becomes less than the speed limit value, the device stop limiting the speed and sounding the alarm
1. Limit speed intelligently according to speed limit values of the road
2. The device is widely applicable, can be used in mostly 12 v ~ 24 v vehicles
3. It is easy to install the device and it is anti-shock
4. Strong stability: Design of short circuit protection, built-in circuit of preventing over current.
5. Design of combining electronic technology with machinery, one installing for forever.
6. Study intelligently the features of vehicle. It will reduce setting of same kind of vehicle.
7. Alarm of cutting of power wire.
8. Limit speed safely without affecting vehicle's horsepower
Function
1. Feet management
(1)Record the data of running status:
Speed and status of vehicle's running status.
(2) Record the historical route of vehicle.
2. Over speeding alarm and limit vehicle speed
When vehicle speed become over the speed limit value, the device sound the alarm and send the alarming data to the control center. If the driver didn't slow down the car, the device will limit vehicle speed.
3. Function of self-inspection
When the device connects the power, it inspects itself and sound "di" shows that it works well.
4. Function of power-off protection
The device has built-in storage and will update the important data to the control center.
5. Function of anti-interference
The device takes measures to be resistant to interference, so it can ensure the reliability of recorded data.
Main specification
| Item | Specification |
| Size | 155×91×47 mm³ |
| Processing Chips | ARM |
| Speed Limiting Scope | 40-120 Km/h |
| Deviation | ±5 Km/h |
| Bearing Capability | 400N |
| Operating Voltage | DC 9V—36V |
| Power Dissipation | 10W |
| Working Current | <200mA |
| Operating Temperature | -40°C to +85°C |
| Operating Humidity | 20%--90% |
Function of self-inspection
When the device connects the power, it inspects itself and sound "di" shows that it works well.
Speed limit mode
The device's default mode is Mode 1
| Item | Specification |
|
1.Intelligent Speed Limit |
Limit speed intelligently according to speed limit value of the road
For example, when the speed limit value of the road is 80 Km/h, the device will limit vehicle speed to be less than 80 Km/h. when the speed limit value of the road is 100 Km/h, the device will limit vehicle speed to be less than 100 Km/h |
|
2. Fixed Speed Limit |
Limit speed according to types of vehicle.
For example, we set the speed limit value be 100 Km/h, the device limit vehicle speed to be less than 100 Km/h |
|
3.Speed Limit for Each Period of Time |
Set different speed limit value for different period.
For example, we set the speed limit value be 50 Km/h for 2:00 A.M. to 5:00 A.M. and 80 Km/h for other time in one day. So the device will limit vehicle speed to be less than 50 Km/h at 2:00 A.M. to 5:00 A.M. and less than 80 Km/h at 0:00 A.M to 2:00 A.M. and 5:00 A.M. to 24:00 |
|
4.Speed Limit for Each Type of Vehicle |
Set different speed limit value for different type of vehicle.
For example, the device limit the car speed to be lees 120 Km/h, the bus speed to be less than 100 Km/h and the speed of delivery vehicle for dangerous cargo to be less than 80 KM/h |
|
5. Speed Limit for Vehicle on Each Type of road |
Set different speed limit value when the vehicle is on different type of road
For example, the device limit vehicle speed to be less than 120 Km/h when the device is on the expressway, 100 Km/h on the fast road, 60 Km/h on the national road and 50 Km/h on the county road. |
| 6. Speed Limit for Different Combined Condition | Set different speed limit value according to combined condition including period of time, type of vehicle and type of road.
For example, according to the setting, the device can limit bus speed to be less than 100 Km/h when the bus run on expressway from 8:00 A.M. to 10:00 A.M. and limit bus speed to be less than 80 Km/h when the bus run on expressway from 18:00 to 21:00. |
Function of Speed Limit
When vehicle speed reach the speed limit value, the device sound the alarm ("di", "di", "di" ring slowly)
When vehicle speed is more 10% than the speed limit value, the device will limit vehicle speed to make it less than the speed limit value ("di", "di", "di" ring fast)
When vehicle change lanes, the device will stop limiting vehicle speed and sound the alarm ("di", "di", "di" ring fast)
When vehicle speed becomes less than the speed limit value, the device stop limiting the speed and sounding the alarm
