LED Video Wall P6.25

SMD P6.25 Outdoor Full Color LED Screen Parameter

No.TypeFull Color
1. Pixel Configuration: 1R+1G+1B
2. Module Resolution:16pixels(H)×32pixels(W)
3. Module Dimension:100mm(H)×200mm(W)×160mm(L)
4. Power Consumption(average): 600w/ m2
5. Power Consumption(max):1000 w/ m2
6. Density: 25600pixels/m2
7. Brightness: >6500 nits
8. Color: 16.7 M
9. Brightness Control: Manual/Auto
10. Gray Scale Rectification: rrectification
11. Picture Regulation Contrast: Chroma regulation/Module brightness regulation
12. Drive Mode: 1/4 duty
13. Refresh Rate960HZ
14. Control Mode: Synchronization control
15. Video Interface: S-Video, VGA, DVI etc.
16. Life Time: 100,000 hours
17. Mean Time To Failure: >10,000 hours
18. Blind LED: None
19. Temperature: -35°C~+55°C
20. Relative Humidity: 10%-95%RH
21. Display Flatness: The display:±1mm Gap between modules:1mm
22. Display Information: Text, Video and Picture etc.
23. Voltage: 220V±10%,380V±10%
24. Communication Distance: <20km
25. Waterproof: IP65
