Double Loop Detector for Car Parking Solution

Products info:
ACM704 Double Loop detector, Car Park Management System with 50uH to 1, 000uH Ideal Loop Inductance and Two-way Output Relays.
Key Specifications/Special Features:
WJDG201 has two-way output relays
One is unlimited output when loop is temporarily covered, while the other is multi-mode that can be set by users
Operation Voltage: AC 220V± 10%
Power consumption: Output: Relay output
Frequency range: 20kHz to 170kHz (4 grades adjustable)
Reaction time: 20ms
Sensitivity adjusting: 10 grades
Loop inductance:
Ideal: 100uH to 300uH (include connecting wiring)
Maximum: 50uH to 1000uH (include connecting wiring)
Loon connection wiring: Recommend down-lead not more than 100 meters, twist 20 times at least per meter for the loop, total resistance ≤ 10 Ohm
Connection method: 11-pin socket
Shell: PC and ABS engineering plastics
Installation: DIN rail
Operation temperature: -30 to 70 centigrade
Storage temperature: -40 to 85 centigrade
Relative humidity: ≤ 95% RH
Dimensions: 110 x 60 x 100mm (include base socket)
Weight: 400g (include base socket)
