Trimax 6600 sat finder

Specifications
System capabilities Fully DVB compliant Yes
LNB/Tuner input
Connector F type, male
Frequency range 950MHz-2150MHz
Signal lever -90dBm~-0dBm
LNB supply 13/18V, max400mA
LNB switch control 22kHz
DiSEqC Ver 1.0
Demodulator
Front end QPSK
Symbol rate 2Mbps~45Mbps
SCPC and MCPC
Capable
Yes
Spectral inversion Auto conversion
System resource
Processor 32bit processor (200MHz)
SDRAM 16Mbyte
FLASH 2Mbyte
EEPROM 8Kbyte
Video decoder
MPEG 2 Main Proflie@Main Level
Data Rate up to 15M bits/s
Resolution 720*576, 720*480
Video format PAL/NTSC/SECAM
MPEG Audio
MPEG 1 layer 1&2
Type Mono
Sampling rates 32, 44.1 and 48kHz
Serial data
Interface
Connector USB type
Power supply Li-oN Battery 1950 mA
Supply voltage 12.6Volt
Charger 90-240V
Panel connectors Digital tuner input F type, male
Physical
Specification
Size 9.5x15.5x4.5 (cm)
Weight(Net) 0.5 Kg
