Used for Headset Earphone Rotary Potentiometers (R1001N-A)
- Payment Type:
- T/T, Western Union
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Potentiometer Made in China |
|---|---|
| Payment Type: | T/T, Western Union |
Product Description
Product Description
Electronic component Vertical Rotary Potentiometers (R1001N-A)
Electronics china are leading potentiometer supplier in china.we are
specializing in producing and developing potentiometers,Slide potentiometers,Encoders,Switchs for many years.With competive price and high quality.
Mechanical characteristics:
Total rotation angle: 270° +_5°
Rotation torque: 1-10mN. M(10-100gf. Cm)
Push pull strength: 10N(1kg)
Rototion stopper strength: 5N(0.5kg)
Electrical characteristics:
Total resistance: 5kΩ -500kΩ
Total resistance tolerance: +_20%
Resistance taper: A, B, C
Rated power: Curve B: 0.03W other than B: 0.0. 2W
Max. Operating voltage: Curve B: 50V other than B: 50V
Residual resistance: Between terminal 1-2: 10 between terminal 2-3: 10
Insulation resistance: More than 100MΩ At DC 250V
Withstand voltage: AC 100V(1 minute)
Gang error: -40dB to 0 dB<=+-3dB
Durability:
Rotational life: 10, 000 cycles
Electronics china are leading potentiometer supplier in china.we are
specializing in producing and developing potentiometers,Slide potentiometers,Encoders,Switchs for many years.With competive price and high quality.
Mechanical characteristics:
Total rotation angle: 270° +_5°
Rotation torque: 1-10mN. M(10-100gf. Cm)
Push pull strength: 10N(1kg)
Rototion stopper strength: 5N(0.5kg)
Electrical characteristics:
Total resistance: 5kΩ -500kΩ
Total resistance tolerance: +_20%
Resistance taper: A, B, C
Rated power: Curve B: 0.03W other than B: 0.0. 2W
Max. Operating voltage: Curve B: 50V other than B: 50V
Residual resistance: Between terminal 1-2: 10 between terminal 2-3: 10
Insulation resistance: More than 100MΩ At DC 250V
Withstand voltage: AC 100V(1 minute)
Gang error: -40dB to 0 dB<=+-3dB
Durability:
Rotational life: 10, 000 cycles
Sample:
1. Sample: we can provide free samples for most of items.
2. Samples time: Need 3-5 days to preparing the samples ,
except some especially items.
Quality Guarantee:
1.Strictly quality Check before leave factory
2.We have ISO9001 ROHS certificates.
Advantage:
1. We are en end manufacturer
2. New design Accepted: As your requirement
3. Good Quality: Strict quality control and good reputation
5. Fast & Cheap Delivery: Big discount from express agent
(Long-term Contract with DHL, FedEx, EMS , UPS, TNT)
