Solenoid Cabinet Lock (MA1206)

Solenoid Cabinet Lock MA1206 is a compact and all-metal lock ideal for cabinets, drawers and lockers. Surface mounting either vertically or horizontally offers easy and flexible installation. MA1206 Solenoid Lock is compatible with any existing access control system or simply controlled through a remote keypad or key switch. The MA1206 Solenoid Lock is energy saving, cost efficient, robust, easy to install and suitable for one or multiple cabinet applications.

Features

Superior heavy duty metal construction
Nickel-plated steel housing¬
Surface-mounted compact electric lock
Symmetry design enable versatile installation and low install cost.
Accepts access control signals from wireless RF key fobs or proximity cards, numeric keypads, card readers,
Can be fitted to locker, mail box and drawers etc

Specifications

Operation Voltage 12VDC ± 10%
Power Consumption 12V DC 600mA
Operation Mode Fail Locked
Length of tongue 10mm
Cycle Rating 600, 000
Working Temperature -25C ~ +80C
Dimension 64mm*40mm*28mm
Weight 150g
Protection Class IP20

Application

Public locker for supermarket, SPA or school
Retail display cases and drawers
Gun or weapon cabinets
File cabinets
Utility cabinets and drawers
