1m Right Angle Mini HDMI Cable (YTX2)

Right angle mini HDMI to HDMI cable/right angle mini HDMI cable
1)High defination multimedia Cables.
2)24K Gold Plated right angle Mini and A male Connector.
3)support 1080P, 1080I.
4)1.3V or 1.4V is available.
5)4P*28AGG(Bare Copper)+1P*28AWG+5C*28AWG+Al-foil+drain; OD: 6.0mm/7.3mm.
6)Length and color are optional. 7)OEM service is welcome.

Right Angle HDMI Cable
Specifications:
@ 90 Degree HDMI Connector;
@ Connector: 24K gold plated;
@ Supports all HDMI devices including 1.3C / 1.4A (optional);
@ Supports resolution up to 4K;
@ Supports high speed transmission up to 10.2Gbps;
@ 3D Over HDMI;
@ All conductor and the shields (braid and drain) are copper;
@ Triple shields, prevents the EMI effectively;
@ Can provide quite long HDMI cable with amplifying signal without power source;
@ Over 30 models for HDMI cable are available

Features:
@ A premium quality 1.3/1.4 HDMI to HDMI cable is suitable for use in HDTV, Home Theater, DVD player, Projector, PS3, xBox360 and other devices;
@ 24k gold plated connector resist corrosion and ensures an optimum connection for maximum signal transfer;
@ High pure oxygen free copper conductor for maximum conductivity and reliability;
@ Transfer digital audio&Video signals at warp speed of 10.2 Gbps per second

Electrical Features:
@ 100% open & short test;
@ Hi-pot: DC 200V 10ms;
@ Insulation resistance: 10m ohm min;
@ Contact resistance: 3 ohm max.
